Specifications Physical Status Form Factor mATX Dimensions 9.6'' x 9.6'' (244 mm x244 mm) Processor System CPU Supports Intel®Xeon®E-2100/E-2200 Series Processors Socket Single Socket LGA 1151 Thermal Design Power Max. 95W Chipset Intel®C246 System Memory Supported DIMM Quantity 4 DIMM slots Supported Type Dual Channel memory technology
DDR4 288-pin ECC/non-ECC UDIMM Max. Capacity per DIMM 32GB Max. DIMM Frequency ECC/Non-ECC UDIMM: 2666/2400/2133 MHz Voltage 1.2V PCIe Expansion Slots (SLOT7 close to CPU) PCIe x 16 - SLOT6: PCIe3.0 x16, auto switch to x8 when SLOT4 is occupied [CPU] PCIe x 8 - SLOT4: PCIe3.0 x8 [CPU] PCIe x 4 - SLOT5: PCIe3.0 x4 [PCH]**Only supported for E3C246D4U2-2L2T PCIe x 1 - SLOT7: PCIe3.0 x1 [PCH] Other PCIe Expansion Connectors M.2 slot - (2230/2242/2260/2280, Supports PCIE3.0(X4)/SATA3) SATA/SAS Storage PCH Built-in Storage - 8 x SATA3 6Gb/s (SATA0-7, SATA_0 supports SATA DOM)
- 7 x SATA3 6Gb/s (SATA1-7) and 1 x M.2 SSD SATA connected*
*The M.2 slot (M2_1) is shared with the SATA_0 connector. When M2_1 is populated with a M.2 SATA3 module, the Pin 7 of SATA_0 is disabled. Ethernet Interface - 10000/1000 /100 Mbps Additional GbE Controller - 2 x RJ45 10G base-T by Intel®X550-AT2
- 1 x RJ45 Dedicated IPMI LAN port by RTL8211E
- Supports Wake-On-LAN - Supports Energy Efficient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI Server Management BMC Controller - ASPEED AST2500 IPMI Dedicated GLAN - 1 x Realtek RTL8211E for dedicated management GLAN Features - Watch Dog
- NMI Graphics Controller - ASPEED AST2500 VRAM - DDR4 256MB (128MBx16) Rear I/O UID Button/LED - 1 VGA Port - 1 x D-Sub Serial Port - 1 USB 3.2 Gen1 Port - 2 USB 3.2 Gen2 Port - 2 RJ45 - 2x RJ45: 2x 10GbE by Intel®X550-AT2
- 1x IPMI dedicated LAN
- LAN Ports with LED (ACT/LINK LED and SPEED LED) HDMI - 1 Internal Connector/Headers Power Connector - 1x (24-pin) + 1x (8-pin) Auxiliary Panel Header - 1 (includes chassis intrusion, location button & LED, and front LAN LED) System Panel - 1 (RST, PWRBTN, HDDLED, PWRLED) Buzzer - 1 Fan Header - 6(1CPU/3Front/2Rear) Thermal Sensor Header - 1 TR1 TPM Header - 1 SGPIO Header - 2 SMBus header - 1 PMBus header - 1 IPMB Header - 1 Clear CMOS - 1 (header and short pin) ME/SPS Recovery - 1 USB 3.2 (Gen1) Header - 1 (supports 2 USB 3.1 Gen1 ports) USB 2.0 Header - 1 (supports 2 USB 2.0 ports) LED Indicators 80 Debug Port LED - 1 Fan Fail LED - 6 (Header) System BIOS BIOS Type - 256 Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8.0 Support
- ASRock Rack Instant Flash Hardware Monitor Temperature - CPU/PCH/DDR/LAN/Storage Temperature Sensing
- MB/Card side/TR1 Temperature Sensing Fan - CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU Temperature)
- CPU/Rear/Front Fan Multi-Speed Control Voltage - Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM, 1.05V_PCH, +BAT, 3VSB, 5VSB Supported OS OS Microsoft®Windows®
- Server 2016 (64 bit)
- Server 2019 (64 bit)
Linux
- RedHat Enterprise Linux Server 6.9 (64 bit) / 7.4 (64 bit)
- SUSE Enterprise Linux Server 12 SP1 (64 bit) /
12 SP3 (64 bit)
- Ubuntu 15.10 (64 bit) / 16.04 (64 bit) Environment Temperature Operation temperature: 10°C ~ 35°C / Non operation temperature: -40°C ~ 70°C Humidity - Non operation humidity: 20% ~ 90% ( Non condensing)
