Motherboard chips
Integrated chips
Sound card/network card
Main chipset
AMD B550
Chipset description
Powered by AMD B550 chipset
Display chips
CPU built-in display chip (CPU support required)
Audio chips
Integrated ROG SupremeFX 7.1-channel audio chip
Network card chip
Intel I225-V 2.5Gb LAN Adapter
Processor specifications
CPU type
AMD Ryzen 3000/4000G/5000/5000G series processors (except R5 3400G/R3 3200G)
CPU socket
Socket AM4
Memory specifications
Memory type
2×DDR4 DIMM
Maximum memory capacity
64GB
Memory description
Support DDR4 5000 (OC)/4800 (OC)/4600 (OC)/4400 (OC)/4133 (OC)/4000 (OC)/3866 (OC)/3600 (OC)/3466 (OC)/3400 (OC)/3200/3000/2800/2666/2400/2133MHz memory
Storage expansion
PCI-E standard
PCI-E 4.0
PCI-E slots
1× PCI-E x16 graphics card slot
Storage interfaces
2× M.2 interface, 4× SATA III interface
I/O interface
USB interface
Back: 4× USB3.2 Gen2 ports (1× Type-C, 3×Type-A), 1 × USB2.0 ports, 1× USB2.0 ports (1× Type-C audio interfaces)
Front: 1× USB3.2 Gen2 ports (1×Type-C), 2× USB3.2 Gen1 ports, 2× USB2.0 ports
Video interface
1× HDMIport,1 × DisplayPort port
Power connector
One 8-pin, one 24-pin power connector
Other interfaces
1× RJ45 network interface, 3 × audio interface
Plate type
Motherboard form factor
Mini-ITX form factor
Dimensions
17.0×17.0cm
Software management
BIOS performance
256Mb Flash ROM，UEFI AMI BIOS
Other parameters
Overclocking function
In the tank
RAID function
RAID 0,1,10 is supported
Wireless capability
Wireless: Support 802.11 a/b/g/n/ac/axWiFi standard, WiFi 6
Bluetooth
Bluetooth 5.1 is supported
operating system
Windows10 64-bit
