Full 30 Days Warranty Guarantee on every item I sell on !Brand Spanking NEW Fully Tested!
Intel NUC 9 Extreme Compute Element 6-Core
Essentials

• Product CollectionIntel® NUC9th Generation
• Model NameIntel® NUC9th Generation
• Code NameCompute Element forNUC 9 EXTREME Computers
• Supported Operating SystemsWindows 11, 64-bit*, Windows 10, 64-bit*
• ChipsetMobile Intel® CM246 Chipset

CPU SPECIFICATIONS

• i7 Total Cores .................... 6Cores
• i7 Total Threads ................. 12Threads
• i7 Max Turbo Frequency ... 4.50GHz
• i7 Base Frequency ............ 2.60GHz

• i7 style="">i7Cache .............................12 MB Intel® Smart Cache

Memory

• Max Memory Size (dependent on memory type)Supports up to 64 GB

• MemoryDDR4-3200Mhz PC4-26500 1.2V SO-DIMM

• Max # of Memory Channels2

• Max Memory Bandwidth52.1 GB/s

• Max # of DIMMs2

• ECC Memory SupportedNO

Storage

• Internal Drive Form FactorM.2 SSD 80mm
• Number of internal drives Supported3(2 on this Element Module & 1 on it's Element Module Board which is not included in this listing)
• Removable Memory Card SlotSDXC with UHS-II support
• M.2 Card Slot (storage)2x via PCH + via CUP (NVMe)


I/O Specifications

• Built in Graphics Output2x Thunderbolt 3, HDMI 2.0a
• # of Displays Supported3
• # of Thunderbolt? Ports2x Thunderbolt? 3
• # of USB Ports11
• USB ConfigurationRear: 4x USB 3.2g2, 2x TB3 (USB 3.2g2); Front: 2x USB 3.2g2; Internal: 2x USB 2.0 header, 1x USB 3.2 Gen2 Type-A
• USB Revision3.2 Gen2, 2.0
• USB 2.0 Configuration (External + Internal)3x int.
• Total # of SATA Ports3
• Max # of SATA 6.0 Gb/s Ports3
• RAID Configuration2x M.2 SATA/PCIe SSD, SATA header (RAID-0 RAID-1)
• Audio (back channel + front channel)7.1 digital; L+R+mic (F); L+R+TOSLINK (R)
• S/PDIF Out ConnectorTOSLINK
• Integrated LANIntel® Ethernet Connection i219-LM and i210-AT
• Wireless IncludedIntel® Wi-Fi 6 AX200 (Gig+)
• Bluetooth Version 5.2
• Additional HeadersCEC, 2x USB2.0, FRONT_PANEL

Expansion Options

• PCI Express RevisionGen3
• PCIe x4 Gen 31
• PCIe x16 Gen 31

Package SpecificationsAdvanced Technologies

• Intel® Rapid Storage TechnologyYes
• Intel® Optane? Memory SupportedYes
• Intel® Virtualization Technology for Directed I/O (VT-d)Yes
• Intel® Virtualization Technology (VT-x)Yes

Security & Reliability

• Intel® Platform Trust Technology (Intel® PTT)Yes
• TPMYes
• Intel® AES New InstructionsYesShipping will be via Fedex Ground or UPS Ground or USPS Ground Advantage at my discretion.
