The MEAN WELL NDR-120 is an economically slim 120W DIN rail power supply series, made to be be installed on TS-35/7.5 or TS-35/15 mounting rails. The body is 40mm in width, which allows for space saving inside the cabinets. The entire series adopts the full range AC input from 90VAC to 264VAC and conforms to BS EN/EN61000-3-2, the norm that the European Union regulates for harmonic current. The NDR-120 is designed with a metal housing that enhances the unit's power dissipation. With working efficiency up to 89%, the entire series can operate at the ambient temperature between -20°C and 70°C under air convection. It is equipped with constant current mode for over-load protection, fitting various inductive or capacitive applications. The protection functions and relevant certificates for industrial control apparatus (UL508, TUV BS EN/EN62368-1, and etc.) makes the NDR-120 a very competitive power supply solution for industrial applications.
The MEAN WELL NDR-120-48 is a reliable and high-performance AC/DC power supply designed for various industrial applications. With its single output of 48V at 2.5A, it delivers a maximum power output of 120W. This power supply is built to provide stable and regulated power to your electrical devices, ensuring their optimal performance and longevity. It features a compact design, efficient energy conversion, and advanced protection mechanisms, including overload, short circuit, and over-voltage protection. The MEAN WELL NDR-120-48 is a versatile and durable power solution that meets international safety standards, making it an excellent choice for industrial and commercial settings.
• 48V DC 2.5A output• Rated power: 120W• AC input voltage range: 90 VAC ~ 264 VAC• Dimensions: 4.47" L x 1.57" W x 4.93" H (113.5mm x 40.0mm x 125.2mm)
