OUTDOOR WIFI · DUAL BAND SERIESAC1200VSAC600 Two dual-band outdoor access points engineered for farms, yards, warehouses and remote sites.
Compare every spec side by side, then pick the reach and resilience your project needs. DUAL BAND 2.4G + 5GPoE POWERED15KV ESD / 4KV LIGHTNING1200MbpsAC1200 SPEED4× 7dBiAC1200 ANTENNAS600MbpsAC600 SPEED-40°CAC600 MIN TEMP📊 Side-by-Side SpecificationsEvery detail at a glance — pick your model with confidenceFeatureAC1200 Speed/Dual Gigabit Port/4x 7dBi Omni AC600 Speed/LAN 100Mbps/2x 7dBi Omni Wireless StandardIEEE 802.11ac (Dual Band)IEEE 802.11 a/b/g/n/acFrequency / Speed2.4GHz (300Mbps) + 5GHz (867Mbps) — up to 1200Mbps2.4GHz (150Mbps) + 5GHz (433Mbps) — up to 600MbpsAntennas4 × 7dBi Omni-Directional (2 × 2.4GHz + 2 × 5GHz)2 × 7dBi Omni-Directional · 2 × RP-SMA ConnectorsEthernet Ports2 × 10/100/1000Mbps (1 × WAN + 1 × LAN)1 × WAN/LAN 100MbpsPoE Power802.3 AT/AF Active PoE & Passive PoE · DC 54V · Adapter 100-240V/50-60Hz802.3 AT/AF Active PoE & Passive PoE · DC 54V Passive / DC 48V ActiveOperation ModesRepeater / AP (Fat & Fit) / Mesh Router / Mesh ExtenderRouter / AP / Repeater / Fit AP (with WAVLINK AC Controller)Max. CoverageOutdoor 300m per unitOutdoor 100–150mMax. Devices64–96 devices · Mesh up to 10 nodes (incl. host)—Weatherproof RatingIP65 Waterproof & Heat-ResistantRobust Weatherproof EnclosureSurge Protection15KV ESD & 4KV Lightning Protection15KV ESD & 4KV Lightning ProtectionOperating Temp.-20°C ~ 50°C-40°C ~ 50°C (-40°F ~ 122°F)Wireless SecurityWPA2-PSK, WPA1-PSK/WPA2-MIX, WPA3-SAE/WPA2-PSK, WPA/WPA2-Enterprise, Open128-bit WPA/WPA2 (TKIP/AES) · WPA-PSK / WPA2-PSKLED Indicators7 × Status LED Indicators6 × Status LED (Power, WAN/LAN, WiFi, 3 × Signal)Reset Button—1 × Reset (8s)Unit Size (no antenna)21.5 × 6.2 × 6.2 cm / 8.5 × 2.4 × 2.4 in18 × 5 × 5 cm / 7.1 × 2 × 2 inAntenna Length25cm / 9.8in25cm / 9.8inBest ForLarge farms, ranches, multi-building Mesh & 4K surveillance — where reach, Gigabit speed and device density matter mostFrigid climates, compact yards and budget installs — where extreme cold tolerance and simple dual-band coverage matter most Coverage distance changes with the actual environment. The PoE converter is not waterproof — please install it indoors. DUAL BAND · MESH · 1200MbpsAC1200 Speed/Dual Gigabit Port/4x 7dBi Omni Model: IP65|300m|4× 7dBi Omni|Dual GigabitLong Range IP65 Waterproof WiFi Repeater with Passive/Active POE · Supports Fat/Fit AP · Dual Band 5G+2.4G · Enterprise-grade Encryption🚀 1200Mbps Dual-Band SpeedUse the WAVLINK WING 12HP to dominate bandwidth-heavy environments with split-scenario optimization. The 5GHz Band (867Mbps) is dedicated to 4K video surveillance feeds, while the 2.4GHz Band (300Mbps) handles 64–96 low-bandwidth IoT devices (smart irrigation sensors, RFID tags, POS systems) without congestion.🕸️ Blanket Every Acre with Mesh NetworkBuild a bulletproof WiFi blanket across vast homesteads with WAVLINK's Everything Mesh Technology. Seamlessly connect your farmhouse, barns, poultry coops, and distant irrigation hubs into one network. As you move from the kitchen to the yard, from the stable to the farm, enjoy uninterrupted connectivity without drops or lags.
Note: Max. 10 nodes supported (including the host device).📡 Industrial-Grade Signal DominancePowered by a high-power chip and 4 × 7dBi antennas (2 × 2.4GHz + 2 × 5GHz), this outdoor WiFi booster expands signal to 300m away per unit (changes with the actual environment), effortlessly linking barns, pastures, and farmhouse basements. Engineered for outdoor scenarios, it juggles 64–96 devices simultaneously — from GPS cattle collars and smart milking systems to 4K yard cams — without throttling.🔌 Dual Gigabit Ports & PoE FreedomEquipped with dual 10/100/1000Mbps Ethernet ports, the outdoor AP enables lightning-fast data transfer rates and provides an extra wired connection possibility for flexible use. 54V Active/Passive PoE allows you to power the device via Ethernet from 100m away, getting rid of risky outdoor wiring.
Note: The PoE converter is not waterproof, please install it indoors.🛡️ Weatherproof Enclosure & Enterprise-grade SecurityIP65 waterproof & heat-resistant case ensures continued operation in harsh outdoor environments, withstanding broad ranges of temperature (-20°C ~ 50°C), while 15KV ESD / 4KV lightning protection prevents damage in electrical surges. Supporting WPA2/WPA3-MIX and WPA/WPA2-Enterprise, this outdoor router is perfect for businesses, organizations, and individuals requiring high-level security.🧩 Fat/Fit AP Mode FlexibilityUnder Fat AP Mode, the repeater works as a regular wireless AP, ideal for quick deployments without complex configurations. Fit AP Mode unlocks centralized control via a WAVLINK AC Controller (sold separately), allowing large-scale management — imagine updating firmware on multiple routers spanning 5,000-acre cattle ranches or balancing bandwidth for 10-villa eco-resorts from one dashboard.📦 IN THE BOX — AC12001 × AC1200 Wireless Outdoor Access Point
4 × Omni Antennas
1 × RJ-45 Networking Cable
1 × Power Adapter
1 × PoE Converter
1 × Main Body Holder
2 × Cable Ties
1 × Screw Fittings
1 × Quick Start Guide💡 WARM TIPS 1. The PoE converter is not waterproof, please install it indoors.
2. Please make sure your Ethernet cable to the outdoor router is CAT5E or above certified and shorter than 100m/328ft.
3. Please install the product 2-3 meters above the ground for better performance.
4. Select the wireless network with a signal strength greater than 70% to get the most reliable connection.
5. Under Mesh Mode, the repeater supports max. 10 nodes (including the host devices). DUAL BAND · 600Mbps · -40°C READYAC600 Speed/LAN 100Mbps/2x 7dBi Omni Model: 100M LAN|100–150m|2× 7dBi OmniComplies with IEEE 802.11 a/b/g/n/ac · Simultaneous Dual Band [email protected] + 433Mbps@5GHz · Easy installation, flexible placement❄️ -40°C Extreme Cold ResistanceBuilt for the harshest climates, this outdoor AP keeps running from -40°C to 50°C (-40°F ~ 122°F) — a wider operating window than most outdoor units on the market. Perfect for cold-storage yards, mountain sites and northern installations where lesser hardware simply shuts down.📶 Simultaneous Dual Band AC600Complies with IEEE 802.11 a/b/g/n/ac standards and delivers simultaneous dual-band throughput — 150Mbps @ 2.4GHz + 433Mbps @ 5GHz. Offload your 5GHz devices for smoother streaming while legacy 2.4GHz gear stays connected.🔌 PoE Power & Multi-Mode FlexibilitySupports 802.3 AT/AF Active PoE and Passive PoE — power the unit over Ethernet and skip risky outdoor wiring. Choose Router, AP or Repeater mode for your scenario, or unlock centralized management via Fit AP with a WAVLINK AC Controller (sold separately).📡 2 × 7dBi Omni Antennas with RP-SMAFeatures 2 × RP-SMA connectors for external antennas, giving you the freedom to swap or upgrade antennas for your exact coverage needs. Outdoors it reaches 100–150m (changes with the actual environment) — ideal for yards, driveways and compact properties.🛡️ Weatherproof Enclosure & Solid SecurityA robust weatherproof enclosure keeps the unit running through rain, dust and temperature swings, backed by 15KV ESD and 4KV lightning protection. Wireless security covers 128-bit WPA/WPA2 (TKIP/AES) plus WPA-PSK / WPA2-PSK encryption.🔧 Easy Installation, Flexible PlacementStraightforward setup and flexible mounting let you get the link up fast — 6 status LEDs (Power, WAN/LAN, WiFi and 3 × Signal) give you clear, real-time response on link quality at a glance. 1 × 100Mbps WAN/LAN port handles the wired side.📦 IN THE BOX — AC6001 × AC600 Dual Band Outdoor Access Point
2 × Omni-directional Antennas
1 × RJ-45 Network Cable
1 × Power Adapter
1 × PoE Converter
1 × Main Body Holder
2 × Cable Ties
1 × Screw Fitting Kit
1 × Quick Start Guide💡 WARM TIPS 1. The PoE converter is not waterproof, please install it indoors.
2. Please make sure your Ethernet cable to the outdoor router is CAT5E or above certified and shorter than 100m/328ft.
3. Please install the product 2-3 meters above the ground for better performance.
4. Select the wireless network with a signal strength greater than 70% to get the most reliable connection. Which One Fits Your Site?AC1200 — Dual Gigabit ports, 4 antennas, 300m reach, Mesh up to 10 nodes and 64–96 devices.
Best for large farms, ranches, multi-building sites and 4K camera deployments.AC600 — 2 antennas with RP-SMA flexibility, 100–150m reach and an outstanding -40°C cold rating.
Best for frigid climates, compact yards and budget-conscious installs.USE THE DROPDOWN ABOVE TO SELECT YOUR MODEL
