PHIHONG POWER OVER ETHERNET POE33U-1AT-R OUTDOOR 56V 100-240V 1A 50-60Hz 33.6W
Price: US $72.80
PHIHONG POE33U-1AT-R OUTDOOR POE 56V 100-240V 1A 50-60Hz 33.6W Power over Ethernet Waterproof Adapter PoE Plus Single Port Injector for Outdoor
Input
AC Input Voltage Range- 90 to 264VAC
AC Input Voltage Rating- 100 to 240VAC
AC Input Current
1.0A (RMS) and 90VAC at maximum load
.55A (RMS) and 240VAC at maximum load
AC Input Frequency- 47 to 63Hz
Leakage Current- 3.5mA for 254VAC, 50Hz
Max Inrush Current
30A for 115VAC at maximum load
60A for 230VAC at maximum load
Output
Total Output Power- 33.6W
Ripple and Regulation- 250mV maximum
Efficiency- 75% (typical) at maximum load, and 120VAC 60Hz
Environmental
Temperature
Operation- -40 to +60°C
Non-operation- -40 to +85°C
Humidity
Operation- 5 to 90%
EMI
FCC Part 15 Class B
EN55022 Class B
Isolation Test
Primary to Secondary- 4242 VDC for 1 minute, 10mA
Primary to Field Ground- 2121VDC for 1 minute, 10mA
Output to Field Ground- 2121VDC for 1 minute, 10mA
Immunity
ESD- IEC61000-4-2 Level 3
RS-IEC61000-4-3 Level 3
EFT- IEC61000-4-4 Level 2
Surge- IEC61000-4-5 Level 3
CS- IEC61000-4-6 Level 3
Voltage Dips- IEC61000-4-11
Harmonic- EN61000-3-2 Class A
Insulation Resistance
Primary to Secondary- >10M OHM 500VDC
Primary to Field Ground- >10M OHM 500VDC
Feature
Over Voltage/Current, Short Circuit Protection- The output is equipped with short-circuit, over-voltage and over-load protection as per the 802.3at specification, and conforms to UL60950-1 paragraph 2.2.3. The output can be shorted permanently without damage
Indicators
LED 1- Input power “ON”
LED 2- Detected a valid IEEE802.3at Class 4 load
LED 3- Detect and Connected to a valid IEEE802.3af load
Input Connector- 3 pin terminal block with M3.5 screw terminal; for appropriate connection use minimum 14AWG wire and M3.5 spade lug
Output PoE Connector- RJ45
Output PoE Connection- +pins 3, 6 / -pins 1, 2
Input/Output Case Ports- 3 ¾ NPT holes compatible with standard ¾ NPT conduit piping or Phihong wire gland PGLAND750 with fully waterproof AC and RJ45 cables.
Network Switch- Network Switch must be Environment Rated B as per paragraph 33.4.1.1 of the IEEE802.3at Security Cameras
