Supermicro SuperServer/SYS-4029GP-TRT2 AI Server

The price includes:

Model: SYS-4029GP-TRT2

CPU: Intel Xeon Platinum 8260Y*2 (TDP:165W/ Single 24 cores 48 threads)

RAM: 256GB (64GB DDR4 2933Y *4)

Graphics card: RTX 3090 24GB public Turbo graphics card *10 (can reduce the number)

System disk: 480Gb SSD *1

Data disk: 300Gb SAS/SATA*23(2.5 inches using the front bracket)

Power supply: 2000W*4 (platinum grade hot swap power supply)

Buyer Notice:

We are not responsible for customs clearance, buyers need to pay customs duties

1.The above accessories are already included in the list price!

2. The above accessories are randomly equipped and can be customized according to the buyer's budget!

3. The server market situation is changing every day, and direct payment is not recommended. Please confirm the price, how long will it take to ship, and then make payment!

4. Used servers require high technical requirements, and each machine is tested for 12 hours before shipment to ensure that each machine is 100% intact!

5. Welcome to leave a comment other questions!

The picture is for reference only

Product SKUs
SYS-4029GP-TRT2

• SuperServer style="box-sizing: border-box; line-height: 0; margin: 0px; display: block; content: "";"/>Super class="desc" style="box-sizing: border-box; margin: 0px; padding: 0px; font-weight: bold; color: rgb(93, 139, 96) !important;">
• Dual Socket P (LGA 3647)
• 2nd Gen Intel® Xeon® Scalable Processors and Intel® Xeon® Scalable Processors‡,
  3 UPI up to 10.4GT/s
• Support CPU TDP 70-205W

Cores

• Up to 28 Cores

Note‡BIOS version 3.2 or above is required to support 2nd Gen Intel® Xeon® Scalable processors (codenamed Cascade Lake-R)

GPU
Supported GPUs

• 10 Double-Width/Single-Width PCI-E 3.0 x16 Card (Full Height Full Length)
• NVIDIA V100, P40, T4, Quadro, RTX
• Supports both active and passive cooled GPUs
• Compatible GPU list

CPU-GPU Interconnect

• PCI-E Gen 3 x16 Switch Single-Root
• PCIe Root Architecture Chart

GPU-GPU Interconnect

• PCI-E, NVIDIA® NVLink™ Bridge (Optional)

System Memory
Memory Capacity

• 24 DIMM slots
• Up to 6TB 3DS ECC DDR4-2933MHz†RDIMM/LRDIMM
• Supports Intel® Optane™ DCPMM††

Memory Type

• 2933†/2666/2400/2133MHz ECC DDR4 RDIMM/LRDIMM

Note†2933MHz in two DIMMs per channel can be achieved by using memory purchased from Supermicro
††Cascade Lake only. Contact your Supermicro sales rep for more info.

On-Board Devices
Chipset

• Intel® C622 chipset

SATA

• SATA3 (6Gbps) with RAID 0, 1, 5, 10

Network Controllers

• Dual Port 10GbE from C622

IPMI

• Support for Intelligent Platform Management Interface v.2.0
• IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

Graphics

• ASPEED AST2500 BMC

Input / Output
SATA

• 8 SATA3 (6Gbps) ports

LAN

• 2 RJ45 10GBase-T LAN ports
• 1 RJ45 Dedicated IPMI LAN port

USB

• 4 USB 3.0 ports (rear)

Video

• 1 VGA Connector

COM Port

• 1 COM port (header)

System BIOS
BIOS Type

• AMI 32Mb SPI Flash class="desc" style="box-sizing: border-box; margin: 0px; padding: 0px; font-weight: bold; color: rgb(93, 139, 96) !important;">
• Intel® Node Manager
• IPMI 2.0
• KVM with dedicated LAN
• SSM,SPM,SUM
• SuperDoctor® 5
• Monitors for CPU Cores, Chipset Voltages, Memory.
• 4+1 Phase-switching voltage regulator

FAN

• Fans with tachometer monitoring
• Status monitor for speed control
• Pulse Width Modulated (PWM) fan connectors

Temperature

• Monitoring for CPU and chassis environment
• Thermal Control for fan connectors
