2 in 1 Out vs 2 in 2 Out Optional - pls choose it correctly according to your need
Following use2 in 2 out HDMI Video Switcher for Live Streaming as introduction
Product Introduction:
Brand new and high quality,buy with cofidence!
This 2 Way HDMI Video Switcher for Live Streaming, it supports 2 HDMI inputs 2 HDMI outputs.
Input and output resolution support 1920X1080@60Hz, and support HDCP1.4 standard.
Support HD embedded audio or external analog audio, , after mixed processing, can be embedded
in the output HD signal or output from the analog port. Suitable for program production, interview and
speech on-site production, outdoor experience events, school courseware production and other
video switching needs. It can be used in live streaming and various event venue.
Features:
*2 HDMI inputs, 2 HDMI outputs;
* One HDMI output supports PVW multi-view preview, another HDMI output supports PGM output;
* 1 way Type-C port UVC capture output;
* Supports OSD display of input channel signals, resolution information, and volume information;
* In the mix mode, HDMI embedded audio select fixed HDMI audio and mix Mic/LINE IN audio;
* Support HD audio following (fixed following PGM);
* One Type-C 3.0 capture and streaming interface supports YUY2 video format and support UVC 1.0;
* Support 4 picture in picture modes(PIP), PIP image enlarged or reduced;
* Support left and right two image, upper and lower image;
* Extensive compatibility: fully supports mainstream live streaming and media software, including
OBS Studio, PotPlayer, and VLC etc.;
* Support power-off save settings;
* High quality keys, color backlight design.
Specifications:
HDMI input resolution 1080P@60Hz
HDMI output resolution 1080P@60Hz
Type-C 3.0 capture and streaming video format YUY2、MJPEG
Supports audio format PCM
The maximum bandwidth transmission 148.5MHz
Maximum transmission rate 1.65 x3Gbps
The input cable length ............................ 1080P/60Hz≤15 m AWG26 HDMI standard cable
The output cable length .......................... 1080P/60Hz≤15 m AWG26 HDMI standard cable
Maximum working current 0.8 A
Power adapter specifications ............. Input AC(50Hz,60Hz)100V-240V; Output: DC/5V 1A
Working temperature range (0℃ to +45℃)
Size 136x98x29(mm)
The weight 185g
Package include：
1. HDMI video switcher for live streaming x1
2. Type-c to USB 3.2 Gen1 cable x1
3. Type-C 5V 1A power adapter x1
4. User manual x1
Without retail box and other accessories,if any need,pls contact us before purchase.
PLS Attention :
