Quectel EM12-G is an LTE Advanced category 12 module optimized specially for M2M and IoT applications. Adopting the
3GPP Rel-12 LTE technology, it delivers M2M-optimized speeds of 600 Mbps downlink and 150 Mbps uplink peak data rates.
Designed in the M.2 form factor, EM12-G is compatible with Quectel Cat 6 module EM06 , which will facilitate customers to
migrate between different categories.
EM12-G is designed for global and nearly covers all the main stream carriers worldwide.
EM12-G, optionally, supports Qualcomm® IZat™ location technology Gen9HT Lite (GPS, GLONASS, BeiDou, Galileo). The
integrated GNSS greatly simplifies product design, and provides quicker, more accurate and more dependable positioning
capability.
A rich set of Internet protocols, industry-standard interfaces and abundant functionalities (USB drivers for Windows 7, Windows
8/8.1, Windows 10, Linux, Android/eCall, etc.) extend the applicability of the module to a wide range of M2M and IoT
applications such as industrial router, home gateway, STB, industrial laptop, consumer laptop, industrial PDA, rugged tablet
PC, video surveillance and digital signage, etc.
Global Model
EM12-G:
LTE FDD: ①/
B30/B32 ①/B66
LTE TDD: B38/B39/B40/B41
DL 2 × CA: Inter-band CA/Intra-band CA
DL 3 × CA: Inter-band CA/Intra-band CA
WCDMA: B1/B2/B3/B4/B5/B8/B9/B19
GNSS: FDD:
Max. 600 Mbps (DL) / Max. 150 Mbps (UL)
LTE TDD:
Max. 430 Mbps (DL) / Max. 90 Mbps (UL)
UMTS:
DC-HSDPA: Max. 42 Mbps (DL)
HSUPA: Max. 5.76 Mbps (UL)
WCDMA: Max. 384 kbps (DL/UL)
SMS
Text and PDU Modes
Point-to-point MO and MT
SMS Cell Broadcast
Storage: ME by default
Audio
Digital Audio Interface:
PCM interface
Speech Codec Modes:
AMR/AMR-WB
Echo Arithmetic:
Echo Cancellation/Noise Reduction
VoLTE (Optional):
CSFB (Circuit Switched FallBack)
VoLTE (Voice over LTE)
Interfaces
(U)SIM: × 2
I2C: × 1
PCM (Digital Audio): × 1
ANTCTL (Antenna Tuner Control)*: × 4
USB 2.0/USB 3.0: × 1
W_DISABLE1#: × 1
RESET#: × 1
WAKE_ON_WAN#: × 1
WWAN_LED#: × 1 (high speed UARTs)
Antenna: × 3 (Main, Diversity&GNSS, GNSS)
Electrical Characteristics
Supply Voltage: 3.135–4.4 V, typ. 3.7 V
Current Consumption (typ.):
56 μA @ Power down
4.0 mA @ Sleep
19.4 mA @ Idle
Output Power:
Class 3 (23 dBm ±2 dB) for LTE FDD Bands
Class 3 (23 dBm ±2 dB) for LTE TDD Bands
Class 3 (24 dBm +1/-3 dB) for WCDMA Bands
Enhanced Features
MIMO (2 × 2, 4 × 2, DL)
Digital Audio & VoLTE (Voice over LTE) (Optional)
(U)SIM Card Detection
DTMF (Dual Tone Multi Frequency)
Dual SIM Single Standby
DFOTA
GNSS
Software Features
3GPP E-UTRA Release 12
USB Serial Driver:
Windows: 7/8/8.1/10
Linux: 2.6–5.4
Android: 4.x/5.x/6.x/7.x/8.x/9.x
RIL Driver:
Android: 4.x/5.x/6.x/7.x/8.x/9.x/10.x
NDIS Driver:
Windows: 7/8/8.1/10
MBIM Driver:
Windows: 8/8.1/10
Linux: 3.18–5.4
Gobinet Driver:
Linux: 2.6–5.4
QMI_WWAN Driver:
Linux: 3.4–5.4
GNSS Driver:
Android: NTP/ TCP/ UDP/ FTP/ HTTP/ PING/ HTTPS
General Features
Temperature Range:
Operating Temperature:
-30 °C to +70 °C;
-10 °C to +65 °C (Only for UL CA test)
Extended Temperature: -40 °C to +85 °C
Dimensions: 42.0 mm × 30.0 mm × 2.3 mm
Package: M.2
Weight: approx. 6.0 g
Approvals
Carrier:
Vodafone* (Europe)
Deutsche Telekom* (Germany)
British Telecom* (British)
Telefónica* (Spain)
Verizon/AT&T/Sprint* (America)
Telus (Canada)
Telstra (Australia)
NTT DOCOMO*/SoftBank* (Japan)
Regulatory:
GCF (Global)
CE (Europe)
PTCRB (North America)
FCC (America)
IC(ISED) (Canada)
KC (South Korea)
NCC (Taiwan, China)
JATE/TELEC (Japan)
RCM (Australia/New Zealand)
ICASA (South * Under Development
2. ① LTE-FDD B29 and B32 support receiving
only, and are only for secondary component
carrier in 2 × CA.
