Product imageProduct modelBATTLE-AX X870A-GHA WIFI V14Product rangeTomahawk seriesChipsetAMD X870CPU supportSupports Ryzen 7000 series, 8000 series, and 9000 series processors
adapted to the AM5 socket of the motherboardMemory supportProvides 4 DDR5 memory slots that can support up to 192 GB of memory capacity (up to 48 GB capacity in a single slot)
- Supports DDR5-7600 (OC) / 7400 (OC) / 7200 (OC) / 7000 (OC) / 6800 (OC) / 6600 (OC) / 6400 (OC) / 6200 (OC) / 6000 (OC) / 5800 (OC) / 5600 (OC) / 5400 (OC) / 5200 (OC) / 5000 (OC) / 4800MHz memory
- supports Intel® Extreme Memory Profile (XMP) memory technology
- supports dual-channel memory technology
Storage interfaceSupports a total of 3 M.2 slots and 4 SATA 6Gb/s HDD interfaces
- M.2_1 slots: Supports 2242/2280/22110 specification M.2 SSDs (PCIe 5.0/4.0 x4, CPU lanes)
- M.2_2 slots: Supports 2242/2280 specification M.2 SSDs (PCIe 4.0 x4, PCH lanes)
- M.2_3 slots: Supports 2242/2280 specification M.2 SSDs (PCIe 4.0 x4, PCH lanes)
Supports creating RAID 0, RAID with M.2 NVMe hard drive devices 1, RAID 5, RAID 10 disk arrayRyzen
9000 series: RAID 0/1/5/10
Ryzen 8000 series: RAID 0/1
Ryzen 7000 series: RAID 0/1/10
*Supported RAID specifications are related
to the CPU paired with the motherboard*PCIe 5.0 support is related
to the CPU paired with the motherboard*When the M.2_3 slot uses M.2 hard drives, the PCIe 4.0 x4 slot will be shieldedExtension interfaceRear I/O ports:
- 2 USB 2.0 ports
- 4 USB 3.2 Gen 1 Type-A ports
- 1 USB 3.2 Gen 2 Type-A port
- 1 USB4 Type-C port (*supports video output, up to 4K 60Hz resolution)
- 1 DP 1.2 port, supports up to 4K 60Hz resolution
- 1 HDMI 2.0 port, supports up to 4K 60Hz resolution
- 1 5G network interface<b17 > - 2 Wi-Fi 6 antenna ports
- 6 audio ports (audio input/audio output/microphone)
- 1 BIOS update button
Onboard device interfaces:
- 1 CPU fan pin
- 3 system fan pins
- 1 water pump pin
- 2 USB 2.0 pins expandable 4 USB 2.0 Type-A ports
- 1 USB 3.2 Gen 1 pin expandable 2 USB 3.2 Gen 1 Type - A Connector
- 1 x USB 3.2 Gen 2 Type-C Slot Expandable 1 x USB 3.2 Gen 2 Type-C Connector
- 3 x 5V 3-pin ARGB Pins
- 1 x 12V 4-pin RGB Pin
- 1 x Front Audio Pin
- 1 x Front Panel Pin
- 1 Speaker Pin
- 1 Serial Pin
- 1 x Clear CMOS Jumper
- 1 x BIOS Programmer PinExpansion slots1 PCIe 5.0 x16 slot1
PCIe x16 slot (supports PCIe 4.0 x4 format)
1 PCIe 3.0 x1 slot
*When M.2_3 slot uses an M.2 hard drive, the PCIe 4.0 x4 slot will be shieldedSystem BIOS256M UEFI, support for multiple Chinese languagespower managementSupport S3, S4, network S5 wake-up, support scheduled boot, incoming call bootHardware monitoringCPU fan speed controllable, system fan speed controllable, CPU temperature monitoring, system temperature monitoring, and voltage monitoring of each groupOn-board network cardRTL8126-CG 5Gbit network card, AX200 WiFi 6 wireless network card, Bluetooth 5.2Onboard sound cardRealtek ALC897 high-fidelity decoding chip with 7.1 channel supportMotherboard specificationsATX Profile
305mm x 245mm
