Dear customers:
This is Anny's shop, welcome to purchase our items, we will provide excellent products and professional service to you.
We promised all the motherboards are carefully tested, 100% working, No DEFECT, NO FAULT, NO DOA, and shipped in a safe package.
If any problem please contact us, because of the time difference, we may reply you late for hours, please be patient to wait, we must reply you in 12 hours, and give you safisfied item warranty is 90 days, if any problem, we can replace, exchange or refund. But please make sure the item was from me, because our items have warranty mark.


Warm notes:
1. Please DO NOT use fake memory, because most of genuine band motherboards can't support that.
2. Please DO NOT use single-side memory, because some motherboards can't support that.
3. Some CPUs can't be supported by motherboard, please try to update the BIOS, please note that's not motherboard's defect.
4. Some "Can't boot" problem's caused by memory, please clean the memory's gold fingers and clean the motherboard's memory solts.


Official LGA1151 socket 7th/6th generation processors:

Intel® Core™ i7 processor / Intel® Core™ i5 processor / Intel® Core™ i3 processor / Intel® Pentium® processor / Intel® Celeron® processor

L3 cache depends on Z270 Express DIMM slots, *support up to 64 GB

* Due to the limitation of Windows 32-bit operating system, if more than 4 GB of memory is installed, the actual displayed memory capacity will be less than the actual installed memory capacity.

Supports dual-channel memory technology

Support DDR4 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C. ) / 3000(O.C.) / 2800(O.C.) / 2666(O.C.) / 2400(O.C.) / 2133 MHz

Supports ECC Un-buffered DIMM 1Rx8/2Rx8 memory (operating in non-ECC mode)

Support non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory

Supports Extreme Memory Profile (XMP) memory

Display function

Built-in display capable processor - supports Intel® HD Graphics:

1X HDMI interface, can support **4096x2160@24 Hz resolution

* Support HDMI 1.4 version.

Supports *Shared Display Memory*1 GB

Sound effect

Built-in Realtek® ALC887 chip

Support High Definition Audio

Support 2/4/5.1/7.1 channel

Support S/PDIF output

The internet

Built-in Realtek ® GbE network chip (10/100/1000 Mbit)

Expansion slot

1XPCI Express x16 slot, supports x16 running specification (PCIEX16)

* To maximize the performance of the graphics card, be sure to install the *PCIEX16 slot when installing a graphics card.

2XPCI Express x16 slot, support x4 running specification (PCIEX4_1/PCIEX4_2)

3XPCI Express x1 slot

(*PCI Express slots support PCI Express 3.0)

Multiple Display Technology

Supports AMD Quad-GPU CrossFireX™ and 2-Way AMD CrossFire™ technology

Storage device interface

Built into the chipset:

1XM.2 socket (support Socket 3, M key, type 2242/2260/2280 SATA and PCIe x4/x2 SSD)

6XSATA 3.0 interface

Supports RAID 0, RAID 1, RAID 5 and RAID 10 into the chipset:

6XUSB 3.1 Gen 1 ports (4 on the rear panel, 2 need to be connected to the USB socket in the motherboard via a flat cable)

6XUSB 2.0 ports (2 on the rear panel, 4 need to be connected from the USB socket in the motherboard via a flat cable)

Internal socket

1X 24PIN motherboard power socket

1X8PIN CPU power socket

1XCPU fan socket

2X System Fan Socket

1x System Fan/Water Cooling Pump Socket

6XSATA 3.0 interface

1XM.2 Socket 3 socket

1X Front Panel Socket

1X Front Side Bus Socket

1XS/PDIF output socket

1XUSB 3.1 Gen 1 socket

2XUSB 2.0 sockets

1X Security encryption module (TPM) socket

1X onboard COM socket

1x Clear CMOS data pins

Rear panel unit connection socket

1XPS/2 keyboard socket

1XPS/2 mouse socket

1X HDMI interface

4XUSB 3.1 Gen 1 interface

2XUSB 2.0 interface

1XRJ-45 network cable interface

3X audio interface (audio in, audio out, microphone)

I/O Controller

Built-in iTE® I/O controller chip

BIOS

2X64 Mbit flash

Use an authorized AMI UEFI BIOS

DualBIOS™ support

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Operating system

Support Windows 10/8.1 64-bit

Support Windows 7 32-bit/64-bit

* Supported OS versions vary by processor.

Form Factor

ATX; 30.5cm x x motherboard

2 x SATA cables

1 x I/O shield

Shipping & Handling:
1. Usually we need 1-2 days to process the items and prepare to ship it. According to your country, we will use the DHL, EMS, UPS, TNT, DPEX expedited shipping, the tracking number can be offered and tracked.
2. The shipping fees have included the local handing and packaging cost. We will send your item base on your address showed on order page. If your address is P.O.BOX, please give us physical address.
3. We can not mark item as "gift", because the custom office and international government regulations prohibit such behavior, thank you for your understanding.


Custom tax:
1. Please note we're unable to take any responsibility for any custom delay or tax. The fees of import duty/tax are not included in the item price or shipping fee, these are the buyer's responsibility.
2. Please check with your local custom office to determine what these additional costs would be before payment. And these fees are normally collected by the delivery company, when you pick up item.


Customer service:
Dear buyers, we sincerely do business with you. If you satisfy with our service and products, please leave us a good response. Your great comments will lead us to get more potential customers, and make us more confident to develop business and serve you better.
But if you don't satisfy with the item, or you have any concern about our transaction, please do first contact us, we will response you in 12 hours, and do our best to help you solve any problems.


Return policy:
Dear buyer, every item is very valuable to us, please know that we won't send bad products, but in case you need replace, exchange or refund, please read folloing policy.
1. Refund. Please send back the item in original package with all the accessories. When you shipped back, please give us tracking number. We'll refund all your money, as soon as got the returned package.
Please note if the package was loss, we only can refund you the shipping cost you paid. If the accessories was not complete, we need the compensation of the lost parts. If the mobo returned with wilful damage, we need the compensation.
2. Replace. Please send back the item in original package, needn't return any accessories. When you shipped back, please give us the tracking number. We'll resend another mobo to you, as soon as we got the returned package.
Please note if the package was loss, we don't resend you any more, then refund you the shipping cost you paid. If the mobo returned with wilful damage, we need the compensation.
