- Supports up to 8 x Dual slot Gen4 GPUs
- Dual AMD EPYC™ 7003/7002 Series Processors
- 8-Channel DDR4 RDIMM/LRDIMM, 32 x DIMMs
- 2 x 1Gb/s LAN ports via Intel®I350-AM2
- 8 x 2.5" SATA hot-swap bays
- 8 x FHFL PCIe Gen4 x16 slots for GPUs
- 1 x LP PCIe Gen4 x16 slot
- 2+1 2200W 80 PLUS Platinum redundant power (WxHxD, mm)4U
448 x 176 x 880MotherboardMZ52-G40 Rev. 3.0CPUAMD EPYC™ 7003 Series Processors
AMD EPYC™ 7002 Series Processors
Dual processor, cTDP up to 280W
[Note]If only 1 CPU is installed, some PCIe or memory functions might be unavailable.Socket2 x LGA 4094
Socket SP3ChipsetSystem on ChipMemory32 x DIMM slots
DDR4 memory supported
8-Channel memory per processor
RDIMM/LRDIMM: Up to 3200/2933 MT/s[1]
[1]Follow BIOS setting and memory QVL if running 3200 MT/s with 2DPC.LANFront:
2 x 1Gb/s LAN (1 x Intel®I350-AM2)
- Support NCSI function
1 x 10/100/1000 Mbps Management LANVideoIntegrated in ASPEED®AST2500
- 1 x VGA portStorageFront hot-swap:
8 x 2.5" SATA[1]
- (SATA from CPU_0)
[1]SATA devices supported only.SASN/ARAIDRequire RAID add-in cardsPCIe Expansion Slots4 x FHFL x16 (Gen4 x16), from CPU_0, for GPUs
4 x FHFL x16 (Gen4 x16), from CPU_1, for GPUs
1 x LP x16 (Gen4 x16), from CPU_1[1]
[1]SAS cards are not supported with internal cables due to cable routing limitations.
[Note]The system is only validated with a uniform GPU model.Front I/O2 x USB 3.0 ports (Type-A)
1 x VGA port
2 x RJ45 ports
1 x MLAN port
1 x Power button with LED
1 x ID button with LED
1 x NMI button
1 x Reset button
1 x Storage activity LED
1 x System status LEDRear I/ON/ABackplane BoardSpeed and bandwidth:
SATA 6Gb/sSecurity Modules1 x TPM header with SPI interface
Power Supply[#1]2+1 2200W 80 PLUS Platinum redundant power supplies[1]
AC Input:
- 100-127V~/ 14A, 47-63Hz
- 200-240V~/ 12.6A, 47-63Hz
DC Input:
- 240Vdc/ 12.6A
DC Output:
- Max 1200W/ 100-127V~
+12.12V/ 95.6A
+12Vsb/ 3.5A
- Max 2200W/ 200-240V~ or 240Vdc Input
+12.12V/ 178.1A
+12Vsb/ 3.5A
System Management
ASPEED®AST2500 Baseboard Management Controller
GIGABYTE Management Console web interface
- Dashboard
- JAVA Based Serial Over LAN
- HTML5 KVM
- Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
- Sensor Reading History Data
- FRU Information
- SEL Log in Linear Storage/Circular Storage Policy
- Hardware Inventory
- Fan Profile
- System Firewall
- Power Consumption
- Power Control
- LDAP / AD / RADIUS Support
- Backup & Restore Configuration
- Remote BIOS/BMC/CPLD Update
- Event Log Filter
- User Management
- Media Redirection Settings
- PAM Order Settings
- SSL Settings
- SMTP Settings
OS CompatibilityCitrix Hypervisor 8.2.0 or later
Red Hat Enterprise Linux 8.3 or later
Red Hat Enterprise Linux 9.0 or later
SUSE Linux Enterprise Server 12 SP5 or later
SUSE Linux Enterprise Server 15 SP2 or later
Ubuntu 18.04.5 LTS or later
Ubuntu 20.04 LTS or later
Ubuntu 22.04 LTS or later
VMware ESXi 6.7 Update3 P03 or later
VMware ESXi 7.0 Update1 or later
VMware ESXi 8.0 or later
Windows Server 2016 (X2APIC/256T not supported)
Windows Server 2019
Windows Server 2022System Fans12 x 60x60x38mm (21,700rpm)Operating PropertiesOperating temperature: 10°C to 35°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)WeightNet Weight: 30.2 kgPackaging Dimensions1109 x 609 x 606 mmPackaging Content1 x G482-Z52
2 x CPU fansinks
8 x GPU power cables (CPU 8pin, 100mm)
1 x L-shape Rail kit
|
|
