Supports the following processors: Intel® Core™ i7 processor, Intel® Core™ i5 processor, Intel® Core™ i3 processor, Intel® Pentium® processor, or Intel® Celeron® processor
The L3 cache is CPU dependent
Chipset
Intel® B150 high-speed chipset
Memory
Two DDR4 DIMM slots for up to 32 GB
* Due to the limitation of the Windows 32-bit operating system, if the installed memory capacity exceeds 4 GB, the displayed memory capacity is less than the actual installed memory capacity.
Dual channel memory technology is supported
Supporting DDR4 2133 MHz
Supports ECC UDIMM 1Rx8/2Rx8 memory (non-ECC mode)
Supports non-ECC UDIMMs with 1Rx8/2Rx8/1Rx16 memory
Display function
Built in processor with display function - support Intel® HD Graphics:
1 DVI-D interface, supporting **1920x1200@60 Hz resolution
* This DVI-D port does not support VGA.
1 HDMI interface, can support **4096x2160@24 Hz resolution
* Supports HDMI version 1.4.
Support * Shared display memory *1024 MB
Sound
Built-in Realtek® ALC892 chip
High Definition Audio is supported
Supports 2/4/5/1/7.1 channels
Supports S/PDIF output
Network
Built-in Intel® GbE Network chip (10/100/1000 Mbit)
Wireless communication module
Wi-Fi 802.11a /b/g/n/ac, supporting 2.4/5 GHz dual-band wireless
Bluetooth 4.2, 4.1, BLE, 4.0, 3.0, 2.1+EDR
Support 11ac wireless communication standard, can support **867 Mbps transmission speed
* The actual transmission speed will vary depending on the operating environment and equipment.
Expansion slot
One PCI-E x16 slot supporting x16 specifications
(PCI-E x16 slot supports PCI-E 3.0)
1 M.2 WiFi slot for wireless communication module (M2_WIFI)
Storage device interface
Built in chipset:
One M.2 socket at the back of the mainboard (supports SSD, M key, type 2260/2280 SATA and PCI-E x4/x2/x1 SSD)
Four SATA 3.0 ports
* For details about the combination of M.2 and SATA sockets, see section 1-7 Introduction to Sockets and Jumpers.
USB
Built in chipset:
6 USB 3.0 ports (4 in the rear window of the motherboard, 2 from the onboard USB socket of the motherboard via flat cable)
2 USB 2.0 ports (to be connected from the USB socket in the motherboard through a cable)
Built in chipset +ASMedia® USB 3.1 Controller:
One USB Type-C™ port on the rear panel supports USB 3.1
One USB 3.1 Type-A port (red) on the rear panel
Inscribed socket
1 24PIN motherboard power socket
One 8-pin CPU power socket
Four SATA 3.0 ports
One CPU fan socket
Two system fan sockets
1 motherboard jumper socket
1 front-end audio socket
1 S/PDIF output socket
1 USB 3.0 socket (each socket can connect to two front ports)
1 USB 2.0 socket (each socket can be converted to two front ports)
1 horn socket
One clear CMOS data jumper
1 computer case to open the detection pin
Rear panel device connection sockets
One PS/2 keyboard/mouse port
Two SMA antenna interfaces (2T2R)
One DVI-D interface
One HDMI port
One USB Type-C™ interface, supporting USB 3.1
One USB 3.1 Type-A port (red)
Four USB 3.0 ports
One RJ-45 cable port
One S/PDIF optical fiber output socket
5 audio interfaces (* and bass output, rear horn output, audio input, audio output, microphone)
The I/O controller
Built-in iTE® I/O control chip
BIOS
Two 64 Mbit flash devices
Use authorized AMI UEFI BIOS
Support DualBIOS ™
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
The operating system
Supports Windows 10 64-bit (seventh generation Intel® processors)
Windows 10 64-bit/Windows 8.1 64-bit/Windows 7 32-bit / 64-bit (sixth generation Intel® Processors)
* To install Windows 7, download/install the Windows USB Installation Tool from the website of Jijia.
PCB specification
Mini-ITX; 17.0 cm x 17.0 cm
