Board Size
microATX
244W x 244D mm
Processor Supported
Intel®Xeon®E-2400 Processors
Intel®Pentium®Gold G7400 / G7400T Processor
Single processor, TDP up to 95W
Socket
1 x LGA 1700
Chipset Description
Intel®C262 Chipset
Memory Type
4 x DIMM slots
DDR5 memory supported only
Dual Channel memory architecture
DIMM modules up to 32GB supported
ECC UDIMM modules supported only
Memory speed: up to 4400 MHz (1DPC), 4000 MHz (2DPC/1R), 3600 MHz (2DPC/2R)
Integrated Network
2 x 1Gb/s LAN ports (2 x Intel®I210-AT)
Support NCSI function
1 x 10/100/1000 Management LAN
Integrated Video Controller
Integrated in Aspeed®AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Integrated SAS Controller
N/A
Integrated SATA Controller
8 x 7-pin SATA 6Gb/s ports
Support RAID Function
Intel®SATA RAID 0/1/10/5
Expansion Slot
1 x PCIe x16 (Gen5 x16 bus) slot, from CPU
1 x PCIe x8 (Gen4 x4 bus) slot, from PCH
1 x M.2 slot:
- M-key
- PCIe Gen4 x4, from CPU
- Supports 2280 cards
On-Board Connector
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x M.2 slot
1 x CPU fan header
5 x System fan headers
1 x USB 3.2 Gen1 header
1 x TPM header
1 x Front panel header
1 x Backplane board header
1 x PMBus connector
1 x IPMB connector
1 x Clear CMOS jumper
1 x BMC reset jumper
1 x BIOS recovery jumper
1 x Buzzer
Rear I/O Connectors
2 x USB 3.2 Gen1
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
1 x ID button with LED
TPM
1 x TPM header with SPI interface
Optional TPM2.0 kit:CTM010
OS Driver Supported
Please refer to OS compatibility table in support page
Server Management
Aspeed®AST2600 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
·HTML5 KVM
·Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
·Sensor Reading History Data
·FRU Information
·SEL Log in Linear Storage / Circular Storage Policy
·Hardware Inventory
·Fan Profile
·System Firewall
·Power Consumption
·Power Control
·Advanced power capping
·LDAP / AD / RADIUS Support
·Backup & Restore Configuration
·Remote BIOS/BMC/CPLD Update
·Event Log Filter
·User Management
·Media Redirection Settings
·PAM Order Settings
·SSL Settings
·SMTP Settings
PSU Connector
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
Operating Properties
Operating temperature: 0°C to 40°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Bundle
1 x MX34-BS0
1 x I/O shield
1 x Quick start guide
Single Box dimensions: 321 x 308.5 x 78.5 mm
Carton dimensions: 630 x 420 x 345 mm
Quantity: 10 x single boxes in one carton
Bulk Packaging Content
20 x MX34-BS0
20 x I/O shields
Carton dimensions: 609 x 581 x 362 mm
Ordering Information
Retail: 9MX34BS0MR-000-1*
Bulk: 9MX34BS0NR-000-1*
Part Numbers:
