Description
I-O DATA GV-LSU200 Dual HDMI Capture Card with Switcher & Chroma Key
✨ Overview
The I-O DATA GV-LSU200 is a dual HDMI capture card designed for streamers, educators, and content creators who want to combine two video sources into one polished broadcast. With a built-in switcher, chroma key compositing, and three-channel audio mixing, it delivers professional-level production quality through a simple four-button interface.
⭐ Key Features
- 🎬 Dual HDMI Input Switcher: Connect two HDMI sources and switch or composite them in real time directly on the device
- 🖼️ 11+ Screen Layout Modes: Choose from over 11 configurations including full-screen switching, Picture-in-Picture, and chroma key compositing
- 🎙️ 3-Channel Audio Mixing: Blend audio from two HDMI inputs and a microphone simultaneously; toggle each source on/off with a switch
- 💡 LED Audio Indicators: Visual LED lights illuminate during active audio input so you always know what is live
- 🔘 4-Button Operation: All switcher functions are controlled by just four physical buttons — no complex software setup required
- ⚡ Power Delivery / USB Bus-Powered: Operates via USB bus power or Power Delivery — no separate AC adapter needed
- 🖥️ Broad OS Compatibility: Works with Windows 10, macOS 10.14–11, and Chrome OS
📋 Specifications
- 📥 Input Terminals: HDMI ×2
- 📤 Output Terminal: HDMI ×1
- 🔌 PC Connection: USB Type-C ×1
- 🔗 Interface: USB 3.2 Gen 1 (USB 3.0) / USB 2.0
- 🎞️ Capture Format: YUV (USB 3.0), MJPEG (USB 2.0)
- 🔊 Audio Capture: LPCM / 48 kHz
- 📐 Input Resolution: 1920×1080p @ 60/30 fps
- 📺 Output Resolution: 1920×1080p @ 60 fps
- 📏 Dimensions: 135 × 64 × 18 mm (5.31 × 2.52 × 0.71 in)
- ⚖️ Weight: 180 g (6.35 oz)
- 💻 Compatible OS: Windows 10 (versions 2004 / 20H2 / 21H1), macOS 10.14, macOS 10.15, macOS 11, Chrome OS
- 🖱️ Compatible Machines: Windows PC or Mac with USB 3.2 Gen 1 (USB 3.0) / USB 2.0 Standard-A or Type-C connector; Chromebook
📦 What's in the Box
- 🗂️ GV-LSU200 Dual HDMI Capture Unit ×1
- 🔵 USB Cable (A to C, USB 3.2 Gen 1, approx. 0.7 m / 2.3 ft) ×1
- 🟣 USB Cable (C to C, USB 3.2 Gen 1, approx. 0.7 m / 2.3 ft) ×1
- 🟡 HDMI Cable (approx. 1 m / 3.3 ft) ×1
- 📄 User Manual ×1
