About ProductCPU specification
Core quantity
12
The number of Performance-core
8
The number of Efficient-core
4
Thread count
20
Maximum overclocking
4.90 GHz
Intel® Turbo Acceleration Max Technology 3.0 frequency ‡
4.90 GHz
Performance-core Max Turbine acceleration frequency
4.80 GHz
Efficient-core Max Turbine acceleration frequency
3.60 GHz
Performance-core Basic frequency
2.10GHz
Efficient-core base frequency
1.60 GHz
Cache memory
25 MB Intel® Smart Cache
L2 cache total
12 MB
Processor base power
65 W
Upper turbine power limit
180 W
Additional information
status
Launched
Launch date
Q1'22
Embedded options available
no
Conditions of use
PC/Client/Tablet
Data sheet
Immediate view
Memory specification
Maximum memory size (depends on memory type)
128 GB
Memory type
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s
Maximum number of memory channels
2
Maximum memory bandwidth
76.8 GB/s
Extended selection
Direct Media Interface (DMI) revision
4.0
Maximum number of DMI channels
8
ductility
1S Only
PCI Express revision
5.0 and 4.0
PCI Express sets ‡
Up to 1x16+4, 2x8+4
Maximum number of PCI Express lanes
20
Package specification
Supported socket
FCLGA1700
Maximum CPU configuration
1
Heat dissipation solution specifications
PCG 2020C
TJUNCTION
100°C
Package size
45.0mm x 37.5mm
Maximum operating temperature
100 °C
Advanced technology
Intel® Gauss and neuroaccelerator
3.0
Intel® Thread Director
is
Intel® Deep Learning Boost
is
Intel® Optane™ memory ‡ is supported
is
Intel® Speed Shift technology
is
Intel® Turbo Max Technology 3.0 ‡
is
Intel® Turbo Acceleration Technology ‡
2.0
Intel® Hyperthread technology ‡
is
Intel® 64 ‡
is
Instruction set
64-bit
Instruction set extension
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle state
is
Advanced Intel SpeedStep® technology
is
Temperature monitoring technology
is
Intel® Volume Management Device (VMD)
is
Safety and reliability
Intel® Standard Manageability (ISM) ‡
is
Intel® control flow coercion technology
is
Intel® AES Added commands
is
Security key
is
Intel® OS Guard
is
Do disable bits ‡
is
Intel® Boot Guard
is
Pattern Based Executive Control (MBEC)
is
Intel® Virtualization Technology (VT-x) ‡
is
Intel® Virtualization technology (VT-d) ‡ for oriented I/O
is
Intel® VT-x with Extended Page Tables (EPT) ‡
is
