Environment
Temperature: +5° to +40°C (+40° to +104°F)
Humidity: 10-90% RH non-condensing
Interfaces
Standard:
• 10/100BaseT internal Ethernet
• RS-232, up to 115.2 kB/s
• USB 2.0
• Wand interface for EasySet™ System
Optional:
• Wireless internal Ethernet
Wireless:
• Fully integrated IEEE 802.11b/g
• WEP 128 bit, 802.1x/WPA/LEAP/PEAP
• Multiple industrial antenna options for maximized coverage
Supported Protocols:
TCP/IP-suite (TCP, UDP, ICMP, IGMP, etc.), LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMP, SMTP.
SNMP-MIB II supported (over UDP/IP), private enterprise MIB included
Memory
Standard:
4MB Flash memory
16MB SDRAM
1 Compact Flash slot
Maximum:
Flash memory: Up to 16 MB
(optional) 1GB CompactFlash memory
SDRAM: Up to 16MB
Physical Characteristics
LxHxW: 482 x 238 x 275 mm (19.0 x 9.4 x 10.8 in)
Weight: 12.85 kg (28.4 lbs)
Power
115/230VAC auto-switch w/PFC
Voltage Range: 90-265 VAC
Frequency Range: 45-65 Hz
Print Specifications
Max. Print Width:
112 mm (4.4 in) – DT
110 mm (4.3 in) – TT
Min. Width:
50.8 mm (2.0 in)
Thickness:
60 to 250µm (2.4 to 10 mil)
Style:
Roll-fed, die-cut, continuous or fanfold labels, tags or tickets
Label Roll max diameter:
213 mm (8.38 in)
Label Roll Core:
38-76 mm (1.5-3.0 in)
Media Type:
Thermally sensitive media
Resolution:
8 dots/mm (203 dpi)
11.8 dots/mm (300 dpi)
16 dots/mm (400 dpi)
Print Speed:
300 mm/s (12 ips)
