Basic specifications:

Motherboard size

M-ATX(245*245mm)

CPU

Support AM5 socket, Ryzen7000/Ryzen8000/Ryzen9000 series processors

Chipset

AMD® X870 chipset

memory

4 DIMM DDR5 memory bays support up to 192GB in total, support dual-channel memory technology, support memory overclocking, support memory frequency

• shown
• 1 HDMI™ 2.0 display interface, supporting the highest 4K@60Hz video output; 1 DP 1.4 interface supports specified maximum 4K@120Hz or 8K@30Hz video output

• Extension interface
• 1 x PCIe x16 slot (supports PCIe 5.0 x16 mode)

• Audio
• Integrated REALTEK ALC1220 sound card chip

• Internet
• 1 x Realtek RTL8126 5Gb Ethernet Interface；1 x MediaTek MT7925 WIFI7Wireless network adapter, supports Bluetooth 5.4

• storage
• Supports a total of 3 x M.2 slots and 2 x SATA 6Gb/s interfaces
  from AMD® Ryzen™ processors:
  M.2_A Socket (Key_M): Supports PCle 5.0 x4 mode, supports 2280 gauge
  From AMD® X870 chipset:
  M.2_B Socket (Key_M): Supports PCle 4.0 x4 mode, supported 2280 Form
  Factor M.2_C Slot (Key_M): Supports PCle 4.0 X4 mode, supports 2280 Specification, and is located on the back of the motherboard

• USB
• Onboard USB (7 ports in total): 1 x USB 5G header with 2 additional USB 5G ports, 2 x USB 2.0 headers with support for 4 additional USB 2.0 ports, 1 x USB-C front connector with 1 additional USB-C 10G connector; Rear USB (10 ports in total): 6 x USB 5G Type-A ports, 2 x USB 2.0 Type-A ports, 2 x USB4 40G ports
• In-board socket
• 1 x 24Pin ATX Power Connector, 2 x 8 Pin +12V Power Connector, 1 x 4 Pin CPU_FAN Fan Header, 1 x 4 Pin PUMP Water Cooled Pump Header, 1 x 4 Pin MEM_FAN Memory Fan Header, 3 x 4 Pin SYS_FAN Chassis Fan Header

• Supported operating systems
• Windows® 11， Windows® 10 64-bit
• Unique features
• Maxsun View display, 80Code LED digital display, CLR_CMOS shortcut buttons, active air duct optimization, Maxsun Sync light control
