It’s time to supercharge your home network with theGeneration 6 wirelessnetwork and our latest addition to the beloved hAP series. hAP ax² has everything you might need in a primary home access point – and more! Forget endless reviews and comparisons – this is the perfect device for 99% of homes.
Wireless signal is now stronger than ever.Here are the two main ingredients of hAP ax’s success: a state-of-the-art dual-band, dual-chain 4-4.5 dBi radio, and the 802.11ax standard with Wave2 support. Let’s compare it to the previous generation: depending on your overall setup, that meansup to 40% higher speed in the 5 GHz and up to 90% higher speed in the 2.4 GHz spectrum!
Some might ask – why do we even need higher wireless speeds? Well, countless use cases have been previously impossible or difficult to pull off. For example, working with large media files over the wireless network – without the need to download and upload everything. Do you really have the time to wait? Grab a hAP ax² and save more time for the essential things in life!
The modern quad-core CPU running at 864 MHz combined with a solid GB of RAM packs a hefty punch when it comes to heavy operations likecomplex firewall rules, IPsec hardware encryption, using more threads or experimenting with the most advanced RouterOS features. And with the addition of WPA3 advanced encryption support, you’re safer than ever before.
Like the previous models, hAP ax² can be mounted vertically, horizontally, or even on the wall – without sacrificing the strong signal.
With so many products and features on the market, even an experienced user can become confused. So it’s time for asimple truth for a simple choice: you can’t go wrong with a hAP ax² in most homes.
SpecificationsDetailsProduct codeC52iG-5HaxD2HaxD-TCArchitectureARM 64bitCPUIPQ-6010CPU core count4CPU nominal frequency864 MHzSwitch chip modelIPQ-6010RouterOS license4Operating SystemRouterOS (v7 only)Size of RAM1 GBStorage size128 MBStorage typeNANDMTBFApproximately 100'000 hours at 25CTested ambient temperature-40°C to 50°CIPsec hardware accelerationYesWireless capabilitiesDetailsWireless 5 GHz Max data rate1200 Mbit/sWireless 5 GHz number of chains2Wireless 5 GHz standards802.11a/n/ac/axAntenna gain dBi for 5 GHz4Wireless 5 GHz chip modelQCN-5052Wireless 5 GHz generationWi-Fi 6Wireless 2.4 GHz Max data rate574 Mbit/sWireless 2.4 GHz number of chains2Wireless 2.4 GHz standards802.11b/g/n/axAntenna gain dBi for 2.4 GHz4.5Wireless 2.4 GHz chip modelQCN-5022Wireless 2.4 GHz generationWi-Fi 6WiFi speedAX1800EthernetDetails10/100/1000 Ethernet ports5Number of 1G Ethernet ports with PoE-out1PoweringDetailsNumber of DC inputs2 (DC jack, PoE-IN)DC jack input Voltage12-28 VMax power consumption27 WMax power consumption without attachments12 WCooling typePassivePoE inPassive PoEPoE in input Voltage18-28 VPoE-outDetailsPoE-out portsEther 1PoE outPassive PoEMax out per port output (input 18-30 V)600 mAMax total out (A)0.6 ATotal output current0.6Total output power16.8WCertification & ApprovalsDetailsCertificationCE, FCC, IC, EAC, ROHSIP20OtherDetailsCPU temperature monitorYesMode buttonYes
