C9200L-24T-4X-E Overview

C9200L-24T-4X-E is the Catalyst 9200L 24-port Data 4x10G uplink Switch, withNetwork Essentials software. Cisco® Catalyst® 9200 Series switches extend the power of intent-based networking and Catalyst 9000 hardware and software innovation to a broader set of deployments. With its family pedigree, Catalyst 9200 Series switches offer simplicity without compromise – it is secure, always on, and IT simplified.

Quick spec of C9200L-24T-4X-E

• Model: C9200L-24T-4X-E
• Downlinks total 10/100/1000 or PoE+ copper ports: 24 ports data
• Uplink configuration: 4x 10G fixed uplinks
• Default primary AC power supply: PWR-C5-125WAC
• Fans: Fixed redundant
• Software: Network Essentials
• Stacking bandwidth: 80 Gbps
• DRAM: 2 GB
• Flash: 4 GB
• Switching capacity: 128 Gbps
• Forwarding rate: 190.4 Mpps
• Chassis Dimensions: 1.73 x 17.5 x 11.3 in 4.4 x 44.5 x 28.8 cm

C9200L-24T-4X-E Specification

• Downlinks total 10/100/1000 or PoE+ copper ports:24 ports data
• Uplink configuration:4x 10G fixed uplinks
• Default primary AC power supply:PWR-C5-125WAC
• Fans:Fixed redundant
• Software:Network Essentials
• Chassis Dimensions:1.73 x 17.5 x 11.3 in 4.4 x 44.5 x 28.8 cm
• Virtual Networks:1
• Stacking bandwidth:80 Gbps
• Total number of MAC addresses:16,000
• Total number of IPv4 routes (ARP plus learned routes):11,000 (8,000 direct routes and 3,000 indirect routes)
• IPv4 routing entries:3,000
• IPv6 routing entries:1,500
• Multicast routing scale:1,000
• QoS scale entries:1,000
• ACL scale entries:1,500
• Packet buffer per SKU:6 MB buffers for 24- or 48-port Gigabit Ethernet models
• Flexible NetFlow (FNF) entries:16,000 flows on 24- and 48-port Gigabit Ethernet models
• DRAM:2 GB
• Flash:4 GB
• VLAN IDs:1024
• Total Switched Virtual Interfaces (SVIs):512
• Jumbo frames:9198 bytes
• Wireless bandwidth per switch:N/A
• Switching capacity:128 Gbps
• Forwarding rate:190.4 Mpps
• Mean time between failures (hours):525,990
