Gigabyte GA-Z97-HD3 V2.1 MotherboardIntroduction

CPU

1. L3 cache varies with CPU
2. Support for Intel® Core™ i7 processors/Intel® Core™ i5 processors/ Intel® Core™ i3 processors/Intel® Pentium® processors/Intel® Celeron® processors in the LGA1150 package
3. Please refer "CPU Support List" for more information

Chipset

Intel® Z97 Express Chipset

Memory

1. 4 x DDR3 DIMM sockets supporting up to 32 GB of system memory
2. * Due to a Windows 32-bit operating system limitation, when more than 4 GB of physical memory is installed, the actual memory size displayed will be less than the size of the physical memory installed.
3. Dual channel memory architecture
4. Support for DDR3 3100(O.C.) / 3000(O.C.) / 2933(O.C.) / 2800(O.C.) / 2666(O.C.) / 2600(O.C.) / 2500(O.C.) / 2400(O.C.) / 2200(O.C.) / 2133(O.C.) / 2000(O.C.) / 1866(O.C.) / 1800(O.C.) / 1600 / 1333 MHz memory modules
5. Support for non-ECC memory modules
6. Support for Extreme Memory Profile (XMP) memory modules

*Please refer "Memory Support List" for more information

Onboard Graphics

Integrated Graphics Processor - Intel® HD Graphics support:

1. 1 x D-Sub port, supporting a maximum resolution of 1920x1200at60Hz
2. 1 x DVI-D port, supporting a maximum resolution of 1920x1200at60Hz
   * The DVI-D port does not support D-Sub connection by adapter.
3. 1 x HDMI port, supporting a maximum resolution of 4096x2160at24Hz or 2560x1600at60Hz
   * Support for HDMI 1.4a version.

Maximum shared memory of 512 MB
Support for up to 3 displays at the same time

Audio

1. Support for S/PDIF Out
2. Realtek® ALC887 codec
3. High Definition Audio
4. 2/4/5.1/7.1-channel

LAN

Realtek® GbE LAN chip (10/100/1000 Mbit)

Expansion Slots

1. 1 x PCI Express x16 slot, running at x16 (PCIEX16)
   (The PCIEX16 slot conforms to PCI Express 3.0 standard.)
   * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
2. 1 x PCI Express x16 slot, running at x4 (PCIEX4)
   * The PCIEX4 slot shares bandwidth with all PCI Express x1 slots. All PCI Express x1 slots will become unavailable when a PCIe x4 expansion card is installed.
   * When installing a x8 or above card in the PCIEX4 slot, make sure to set PCIE Slot Configuration in BIOS Setup to x4.
3. 2 x PCI Express x1 slots
   (The PCIEX4 and PCI Express x1 slots conform to PCI Express 2.0 standard.)
4. 2 x PCI slots

Multi Graphics Technology

Support for 2-Way AMD CrossFire™ Technology

Storage Interface

Chipset:

1. 6 x SATA 6Gb/s connectors
2. Support for RAID 0, RAID 1, RAID 5, and RAID 10

USB

Chipset:

1. 6 x USB 3.0/2.0 ports (4 ports on the back panel, 2 ports available through the internal USB header)
2. 8 x USB 2.0/1.1 ports (2 ports on the back panel, 6 ports available through the internal USB headers)

Internal I/O Connectors

1. 1 x parallel port header
2. 1 x 8-pin ATX 12V power connector
3. 3 x system fan headers
4. 1 x CPU fan header
5. 1 x front panel header
6. 1 x 24-pin ATX main power connector
7. 1 x front panel audio header
8. 1 x USB 3.0/2.0 header
9. 1 x serial port header
10. 1 x Clear CMOS jumper
11. 1 x S/PDIF Out header
12. 3 x USB 2.0/1.1 headers
13. 6 x SATA 6Gb/s connectors

Back Panel Connectors

1. 1 x RJ-45 port
2. 2 x USB 2.0/1.1 ports
3. 6 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker Out, Line In, Line Out, Mic In)
4. 1 x HDMI port
5. 1 x PS/2 keyboard/mouse port
6. 4 x USB 3.0/2.0 ports
7. 1 x D-Sub port
8. 1 x DVI-D port

I/O Controller

iTE® I/O Controller Chip

H/W Monitoring

1. CPU overheating warning
2. CPU/System fan speed detection
3. CPU/System fan fail warning
4. CPU/System temperature detection
5. System voltage detection
6. CPU/System fan speed control
7. *Whether the fan speed control function is supported will depend on the cooler you install.

BIOS

1. 2 x 64 Mbit flash
2. Support for DualBIOS™
3. Use of licensed AMI UEFI BIOS
4. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features

1. Support for Q-Flash
2. Support for Xpress Install
3. Support for APP Center
   * Available applications in APP Center may differ by motherboard model. Supported functions of each application may also differ depending on motherboard specifications.
4. Support for Smart Switch
5. Support for EZ Setup
6. Support for Smart Recovery 2
7. EasyTune
8. USB Blocker
9. Smart TimeLock
10. Fast Boot
11. System Information Viewer
12. Support for On/Off Charge

Operating System

Support for Windows 10/8.1/8/7

Form Factor

ATX Form Factor; 30.5cm x 19.0cm

Remark

1. Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
2. Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.
