****listing for one each item only****
HPE PN/ P10180-B21
HPE SPN/ P14488-001P10180-B21 P14488-001 HPE MLX Mellanox MCX623105A-VDAT S200GbE QSFP56 Adapter HPE RENEW OPEN****
P10180-B21 HPE Mellanox MCX623105AS-VDAT Ethernet 200Gb 1-port QSFP56 Adapter for HPE
SKU
P10180-B21
P25960-B21
P13188-B21
P10112-B21
Description
Mellanox MCX623105AS-VDAT Ethernet 200Gb 1-port QSFP56 Adapter for HPE
Mellanox MCX623106AS-CDAT Ethernet 100Gb 2-port QSFP56 Adapter for HPE
Mellanox MCX512F-ACHT Ethernet 10/25Gb 2-port SFP28 Adapter for HPE
Mellanox MCX562A-ACAI Ethernet 10/25Gb 2-port SFP28 OCP3 Adapter for HPE
Card Type/Profile
Stand up
Stand up
Stand up
OCP 3.0
ASIC/Chip
Mellanox MCX623105AS-VDAT
Mellanox MCX623106AS-CDAT
Mellanox MCX512F-ACHT
Mellanox MCX562A-ACAI
PCIe Version
PCIe 4x16
PCIe 4x16
PCIe 3.0 x16
PCIe 3.0 x16
Power Requirement
Typical: 13W
Max: 18.4W
Typical: 13W
Max: 18.4W
Typical: 8W
Max: 10W
Typical: 6.3W
Max: 8.9W
UEFI PXE Boot
√
√
√
√
Legacy BIOS PXE Boot
√
√
√
√
Wake-on-LAN (WOL)
√
Internet Protocol (IP)
IPv4, IPv6
√
√
√
√
Auto Negotiation
1/10/25/40/50/100/200 Gb2
1/10/25/40/50/100 Gb
10Gb, 25Gb
10Gb, 25Gb
iSCSI Remote Boot
UEFI
UEFI
UEFI
UEFI
Tunnel Offload
VXLAN, NVGRE, GENEVE
VXLAN, NVGRE, GENEVE
VXLAN, NVGRE,
GENEVE
VXLAN, NVGRE,
GENEVE
RDMA1
RoCEv1, RoCEv2
RoCEv1, RoCEv2
RoCEv1, RoCEv2
RoCEv1, RoCEv2
Receive Side Scaling (RSS)
√
√
√
√
VMware NetQueue and Microsoft Virtual Machine Queue (VMQ)
√
√
√
√
NPAR
Single Root I/O Virtualization (SR-IOV)
512 total, variable per port
512 total, variable per port
512 VF’s total
512 VF’s total
Data Plane Development Kit (DPDK)
√
√
√
√
Root of Trust
Hardware
Hardware
Firmware
Firmware
Authenticated Updates
√
√
√
√
Secure Boot
√
√
√
√
Audit Log
√
√
√
√
Sanitization
√
√
Notes:1HPE recommends using identical network adapters on both ends of the RoCE connection to avoid interoperability issue
Condition : HPE RENEW OPEN .***100% HPE Genuine Part Guarranteed****NOTE:Lead time might take 4 weeks, Please check lead time or ETA before purchasing if have rush order.NOTE:Pictures is sample pictures ,actual pictures available on request , Please send message.What is the HP Renew Program?The HP Renew Program offers an extensive portfolio of quality remanufactured products as a complement to new HP products. Through an extensive process of remanufacturing and recertification, HP Renew offers current, state of the art technology that is guaranteed to be the same quality and performance you would expect from new,
What does "remanufactured" mean?Remanufactured products are models that have been returned to HP for a variety of reasons and then put through a rigorous refurbishment and testing process to bring them back to "same as new" condition and performance.HP Renew products are not to be confused with "used" or "second-hand" products. Instead, HP Renew offers high quality products that are completely remanufactured and retested by HP. All HP Renew products are Factory-Certified to be fully functional with performance standards equal to their factory new counterparts. The benefit: Factory-Certified HP technology at a lower cost and performance equal to equivalent new products,
