Picocomputer RP6502-PICO DIY 6502 Computer Component Kit Product Overview

This listing is for a component kit for building the Picocomputer RP6502-PICO project. The kit includes the resistors, capacitors, connectors, sockets, headers, tactile switch, and three Texas Instruments 74-series logic ICs listed below.

This is an unassembled electronics project kit intended for hobbyists, retro-computing enthusiasts, and builders who are comfortable with through-hole soldering and electronic assembly.

IMPORTANT — ADDITIONAL PARTS ARE REQUIRED

This kit does NOT include all components required to complete the project. The Raspberry Pi Pico boards and the three ICs listed below must be supplied separately by the buyer.

• Required Raspberry Pi Pico boards — NOT INCLUDED
• W65C02S6TPG-14 — NOT INCLUDED
• W65C22S6TPG-14 — NOT INCLUDED
• AS6C1008-55PCN — NOT INCLUDED

Texas Instruments Logic ICs Included Designator Qty Description Manufacturer Part Number U6 1 74AC00 Quad NAND Texas Instruments CD74AC00E U7 1 74AC02 Quad NOR Texas Instruments CD74AC02E U8 1 74HC30 8-Input NAND Texas Instruments CD74HC30E Complete Included Parts List Designator Qty Description C1-C9, C11 10 0.1uF Axial Ceramic Capacitor, ≥10V C10, C12 2 47uF Radial Ceramic Capacitor, ≥10V R1, R6, R11, R18 4 8.06kΩ Resistor, 1% R2, R7, R12 3 4.02kΩ Resistor, 1% R3, R8, R13 3 2kΩ Resistor, 1% R4, R9, R14 3 1kΩ Resistor, 1% R5, R10, R15 3 499Ω Resistor, 1% R16, R17 2 47Ω Resistor, 1% R19, R22 2 220Ω Resistor, 1% R20, R23 2 100Ω Resistor, 1% R21, R24 2 1.8kΩ Resistor, 1% J1 1 2x12 Pin Header J2 1 2x6 Pin Header J3 1 VGA Jack J4 1 Audio Jack REBOOT 1 Tactile Button U1, U5 2 40-Pin IC Socket U3 1 32-Pin IC Socket U6, U7, U8 3 14-Pin IC Socket U2, U4 4 20-Pin Header Socket PCB1Picocomputer HASL PCB Parts Required But NOT Included

The following parts are required to complete the project and are NOT included with this kit:

• Raspberry Pi Pico boards required by the project
• W65C02S6TPG-14 — 65C02 Processor
• W65C22S6TPG-14 — 65C22 VIA
• AS6C1008-55PCN — SRAM

Buyers should make sure they can obtain these components separately before purchasing this kit.

Assembly Required

• This is an unassembled component kit.
• You will not receive an assembled or operational Picocomputer.
• Soldering equipment and soldering experience are required.
• The builder is responsible for proper component identification, placement, orientation, and assembly.
• Additional hardware listed above must be obtained separately.
• Programming and configuration of the completed system may be required.
• Please review the official project documentation before purchasing and before beginning assembly.

Official Project Documentation

This kit is an independently supplied collection of components intended for use with the Picocomputer RP6502-PICO open-source project.

Official project documentation, firmware, software, assembly information, and other project resources are available at:

picocomputer.github.io

No project-specific assembly instructions or technical support are included with this kit. Questions concerning project assembly, firmware, software, configuration, compatibility, or troubleshooting should be directed to the official Picocomputer documentation and project resources.

We are not the creator or maintainer of the Picocomputer project. Credit for the project design, documentation, firmware, software, and related materials belongs to the project creator and contributors.

Kit Condition & Return Information

This kit contains new electronic components unless otherwise stated.

Please inspect the components and verify the contents of the kit before beginning assembly.

Assembled, soldered, modified, or partially assembled kits cannot be returned.

Shipping & Handling

• Components will be carefully packaged for safe shipment.
• Combined shipping is available — add all items to your cart before checkout.
• International buyers may contact us regarding combined orders.
