RSP-320-5 300W 5V 60A for MEANWELL CNC Power Supply PFC Function LED Signs
Features
-Universal AC input / Full range
-Built-in active PFC function, PF>0.95
-Protections: Short circuit / Overload / Over voltage / Over temperature
-Forced air cooling by built-in DC Fan
-1U low profile 30mm
-Optional conformal coating (RSP-320- CC)
-Built-in fan speed control
-LED indicator for power voltage : 5V
-Rated current : 60A
-Current range: 0 ~ 60A
-Rated power : 300W
-Ripple and noise (max.) Note.2 : 150mVp-p
-Voltage Adj. Range : 4.5 ~ 5.5V
-Voltage Tolerance Note.3: ± 2.0%
-Line regulation : ± 0.5%
-Load regulation: ±1.0%
-Setup, Rise Time : 1500ms, 50ms/230VAC 3000ms, 50ms/115VAC at full load
-Hold up Time (Typ.) : 8ms at full load 230VAC /115VAC
Input
-Voltage range (Note 5.) : 88 ~ 264VAC 124 ~ 370VDC
-Frequency range : 47 ~ 63Hz
-POWER FACTOR (Typ.) : PF>0.95/230VAC PF>0.98/115VAC at full load
-Efficiency(Typ.) : 86%
-Ac current (Typ.) : 5A/115VAC
- Inrush Current (Typ.): 20A/115VAC 40A/230VAC
-Leakage Current : <1mA / 105 ~ 135% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed.
Over voltage : 5.75 ~ 6.75V
Protection type : Shut down o/p voltage, re-power on to recover
Over temperature: 80 5 (TSW1) detect on heatsink of power transistor
Protection type : Shut down o/p voltage, recovers automatically after temperature goes down
