SpecificationQMR Series Digital Signage (QM32R)
Series Name
Series Name
QM32R
Display
Screen Size
32"
Panel Technology
Edge LED BLU
Resolution
1920 x 1080
Brightness
400 nit
Contrast Ratio (Typical)
5000:1
Contrast Ratio (Dynamic )
MEGA
Viewing Angle (H/V)
178/178
Response Time
8ms (Typ.)
Operation Hours
24/7
Connectivity
Input
RGB: Display Port 1.2
VIDEO: HDMI 2.0 x1
HDCP: HDCP 2.2
AUDIO: Stereo Mini Jack, HDMI
USB: USB 2.0 x2
Output
RGB: HDMI 2.0 (Loop-out)
AUDIO: Stereo Mini Jack
External Control
RS232C (In/Out) Thru Stereo Jack, RJ45
Sensor
IR
Power
Type
Internal
Power Supply
AC 100 - 240 V~ (+/- 10 %), 50/60 Hz
Power Consumption (Standby)
0.5 W
Environmental Conditions
Operating Temperature
0℃~ 40℃
Operating Humidity
10~80%
Features
Key
FHD Signage Display, Slim & Light Signage with Built-in MagicInfo S6, SSSP 6.0
Special
HARDWARE: Temperature Sensor, Pivot Display, Clock Battery (168hrs Clock Keeping), Built in Speaker(10W 2ch), Video Wall Daisy Chain (HDCP 2.2 4EA, HDCP 1.4 7EA), IP5x Rating, Wi-Fi/BT
SOFTWARE: Auto Source Switching & Recovery, LFD Home UI, Button Lock, Hot Key Option, Plug & Play (Initial Setting)
SMART Signage Platform
Yes
Wi-Fi
Yes
Bluetooth
Yes
Speaker Type
Built-in Speaker (10W + 10W)
Internal Player
Processor
Cortex A72 1.7GHz Quad-Core CPU
On-Chip Cache Memory
L1 Instruction Cache : 48KB
L1 Data Cache : 32KB
L2 Cache : 2MB
Clock Speed
1.7GHz
Main Memory Interface
2.5GB
LPDDR4 1.5GHz 64bit
Graphics
Graphic Resolution: 1920 x 1080
Output Resolution: 3840 x 2160 (Scale Up From Graphic Processing Result)
Storage
8GB
(3.88GB Occupied by O/S, 4.12GB Available)
Multimedia
Video Decoder: MPEG-1/2/4, H.263, H.264/AVC, UHD H.264/AVC, VC-1, AVS+, HEVC, JPEG, PNG, VP8, VP9
Audio Decoder: AC3 (DD), MPEG
IO Ports
USB 2.0
Operating System
Tizen 4.0 (VDLinux)
Dimensions
Without Stand (W x H x D)
28.55" x 16.52" x 1.36"
Packaging (W x H x D)
31.97" x 20.2" x 4.72"
Bezel Width
8.8mm (U/L/R/B)
Weight
Product Weight
12.57 lbs
Package Weight
17.64 lbs
Accessories
Included in Box
Quick Setup Guide, Warranty Card, Power Cord, Remote Controller, Batteries
Optional Wall Mount Kit
WMN4070SE
Optional Stand
STN-L3240E
Optional Touch Overlay
CML400XK
Mechancial Specs
VESA Mount
200 X 200
Stand Type
Foot Stand (Optional)
