EinScan Rigil Wireless 3D Scanner V1.3 – Tri-Mode Hybrid Laser & VCSEL InfraredPLUSE

FREE 3D Scanning Accessory Pro Kit $399 Value

0.04mm Accuracy | 0.05mm Resolution | 5MP Texture Camera | Marker-Free Scanning

🚀 WIRELESS ALL-IN-ONE SCANNING POWER

Break free from cables. EinScan Rigil offers three modes of operation:

• Standalone Mode (onboard computing – no PC required)

• Wireless PC Mode (Wi-Fi 6 connectivity)

• Wired PC Mode (USB-C high-speed link)

Scan anytime, anywhere without markers, while maintaining professional-grade precision.

🔦 TRI-LIGHT HYBRID SCAN TECHNOLOGY

• v1.2Multi-project alignment supported in standalone mode

• v1.2Marker-free laser scanning supported in standalone mode

• v1.2Marker-free laser scanning efficiency improved by 250% (PC mode)

• v1.2 (25 + 25 crossed laser lines) scanning speed up to 4,800,000 points/s for maximum coverage

• v1.2 Parallel laser scanning speed increased to 1,480,000 points/s (PC mode, +60% efficiency)

• 5MP texture camera captures rich, true-to-life details

Perfect for automotive, engineering, reverse engineering, industrial design, and cultural heritage preservation.

All-In-One Powerful Hardware

32GB DDR5 RAM, 32GB eMMC+ 1TB SSD ROM; Built-in 2 x 6000mAh Replaceable Batteries; 6.4'' 2K AMOLED Touchscreen;

Accuracy

This advanced wireless scanner delivers an impressive volumetric accuracy of up to0.04 + 0.06 mm/m.

Hybrid Types of Light Sources 2 Blue Laser Scan Modes

• 25 + 25 Crossed Laser Lines:For high speed scanning, deliveries top-tier efficiency and flexibility.
• 7 Parallel Laser Lines:For fine details, provides consistent results.

Above 2 laser modes can switch during scanning process, and respective data merged together, to achieve speed and detail in one scanning project.

IR Rapid Scan Mode

• IR Rapid:VCSEL Infrared-powered scanning solution for high efficiency and wide coverage of medium to large objects, with eye safe portrait scanning.

Two Scanners In One

EinScan Rigil's 2 separate groups of cameras are specifically designed to capture different light sources, enables best adaptability to laser and IR light source respectively; to achieve better data recognition under strong environmental light, to ensure precise data captured even in complex lighting environments.

Three Working Modes Unlock MAX Performance And Flexibility

• Standalone Mode:All scanning and processing tasks are completed directly on the hardware, delivering exceptional portability and ease of use.
• Wireless PC Mode:Leveraging built-in Wi-Fi 6, this mode enables seamless wireless scanning and allows connection to a computer for maximum computing power, optimizing performance for complex tasks.
• Traditional PC Mode:Maintaining availability and maximum stability in complex network environments or under restricted network conditions.

Marker-Free Laser Scanning

EinScan Rigil has special feature tracking algorithm, provides a marker-free blue laser scanning mode, enabling better efficient than traditional marker based laser scan and better data quality than marker-free IR scan.

Working Efficiently in Sunlight Outdoors

Both Blue Laser and Infrared VCSEL projectors have strong environment light adaptability, which ensure smooth scanning experience under strong sunlight.

5MP Full Color Laser Scanning

EinScan Rigil is equipped with a 5MP high-definition camera that can restore high-quality texture details in both Blue Laser and IR rapid modes, allowing designers, engineers and artists to maintain a high fidelity of model during the digitization process, providing more precise information for subsequent analysis and creation.

For Prosumer, For Automotive

EinScan Rigil is designed to comprehensively address the 3D modeling needs prosumers in automotive aftermarket. It significantly enhances efficiency in generating high-quality 3D models, combining fast scanning capabilities, streamlined professional workflows, lightweight computing solutions, and rich data editing functions.

EXScan Rigil

EXScan Rigil is a dedicated PC software designed specifically for the EinScan Rigil scanner, covering the full spectrum of advanced professional scanning workflows—from calibration, scanning, data modification, closed surface generation, model editing, to export and sharing.

• High-Speed Scanning and Processing Algorithms
• User-Friendly UI Design
• Professional Modelling Workflow

SHINING 3D Cloud

• Data sharing and collaboration.
• Data storage and management.
• Data measurement.
• Free 5GB space to each Shining3D user.

Applications

The EinScan Rigil combines advanced laser and infrared technologies, making it perfect for capturing challenging surfaces like dark and reflective materials. Whether you're scanning large objects like furniture or intricate details on small parts down to the size of a pen cap, the EinScan Rigil delivers high-resolution results with a point distance as fine as 0.05mm. Its versatile scanning modes, including full-color capture, provide excellent accuracy and detail for a wide range of applications.

• Automotive:The EinScan Rigil is designed with exceptional adaptability, handling diverse surface types effortlessly, including challenging reflective and black surfaces. Its advanced Laser HD mode enhances convenience by enabling marker-free scanning, making it a versatile solution for complex materials and detailed scans.
• Cultural Creation & Art Customization:Equipped with a 5MP texture camera, the EinScan Rigil captures cultural heritage in stunning detail and vibrant color. The markerless laser HD mode delivers highly accurate digitization, preserving legacy artifacts with unmatched precision and true-to-life authenticity.
• AR, VR & Digital Content:for games, animation etc.
• Healthcare:like scanning faces or prosthetics.

EinScan Rigil APP

EinScan Rigil App supports full scanning workflows on the device from calibration, scanning, data modification, closed surface generation, model editing, to export and sharing.

Global Marker Alignment

Multiple Types of Marker Supported 3/6/12 mm

Auto Detecting Plane

Data Quality Indicator

Scan Rewind

Resume Edited Data Scanning

X-Y-Z System Alignment

Model Measure

• 📦 WHAT’S IN THE BOX

• EinScan Rigil Wireless 3D Scanner

• Battery + Battery Compartment & Charging Cable

• Carrying Case

• Calibration Board

• Universal Holder

• Power Adapter

• Type-C to Type-C Cable

• Marker Removal Tool

• 3mm & 6mm Reflective Markers

• Accessories Pro Kit (1 box)

• Cleaning Cloth

• Packing List

• Scanning Software (Online download with Perpetual License, No Ongoing Subscription Fees)

✅ Professional Grade | Marker-Free | Ultra-Portable | Wireless Freedom
