Product SpecificationsModel No.
SST-LC19B-R (black + card reader)

MaterialAluminum front panel, 1.0mm SECC body (LC19R:0.8mm)ColorBlackMotherboardMoDT Micro ATX, Mini-ITX, DTXDrive bayExternal

• Slim optical x 1

Internal

• 3.5" x 1 or 2.5" x 1 (vibration dampening)( LC19R only )

Cooling systemRear

• 1 x 50mm exhaust fan, 2200rpm, 19dBA ( LC19R only )

Top

• Oversized CPU/NB vents

Side

• 3 x 50mm fan slots ( LC19R only )

Limitation of CPU cooler37mmExpansion slot1 (includes 1 x PCI riser card and 1 x PCI-Ex16 riser card) for LC19RLimitation of expansion card, width restriction-6.8”Power supplyFanless120W DC/DCboard & AC adapterLimitation of PSUDC board with external adapterFront I/O portUSB 2.0 x 2

IEEE1394 x 1

audio x 1

MIC x 1

52-in-1 card reader (LC19R only)Dimension390 mm (W) x 68 mm (H) x 348 mm (D), 9.2 liters
15.35" (W) x 2.68" (H) x 13.7" (D), 9.2 litersNet weight
4.59kg (LC19B-R, LC19S-R)ExtraSlim optical drive＊MoDT motherboard recommended.＊CPU cooler cannot exceed 37mm in height.＊Card reader supportSmart Media -SM, SSFDC, SM Ram, XDCompact Flash -CF I, CF II, Hitachi Microdrive, IBM Microdrive, Magicstor, HS-CF, Extreme CF, Extreme III CF, Ultra CF, Ultra II CF, Ultra-X CFSecure Digital-SD, HS SD, Extreme SD, Extreme III SD, Ultra SD, Ultra II SD, Ultra II SD plus, SD Elite Pro, *Mini-SD, *Micro SD, *T Flash, *C-Flash, SDHC cardMultimedia -MMCI, MMCII, HS MMC, DV-RS-MMC, *MMC Mobile, *RS MMC, *RS MMC Mobile, *HS RS MMCMemodery Stick -MS, MS Magic Gate, MS Pro, MS Pro(MG), Extreme MS Pro, Extreme III MS Pro, HS MS Pro, HS MS MG Pro, MS Select, MS Pro Ultra II, *MS Duo, *MS Duo(MG), *MS Pro Duo, *MS Pro Duo(MG), *HS MS Pro Duo, * HS MS MG Pro Duo, *MS Pro Duo Ultra II, * MS Rom
