OVERVIEWUPC Code037332124555UPS TypeLine-InteractiveINPUTInput PhaseSingle-PhaseRated input current (Maximum Load)4.1A (220V),3.9A (230V), 3.8 (240V)Nominal Input Voltage(s) Supported220V AC; 230V AC; 240V ACUPS Input Connection TypeC14 inletUPS Input Connection DescriptionIEC320-C14 input connection accepts a variety of detachable cordsets to match country or site-specific wall receptaclesOUTPUTOutput Capacity (VA)1500Output Capacity (kVA)1.5Output Capacity (Watts)900Output Capacity (kW)0.9Nominal Voltage Details230V default (voltage selection via back panel switches)Frequency Compatibility50 / 60 HzFrequency Compatibility DetailsAutomatic frequency selectionOutput Voltage Regulation (Line Mode)-9% / + 5%Output Voltage Regulation (Battery Mode)+/- 5%Included Output Power CablesIncludes 2 C13 to C14 output power cablesOutput AC Waveform (AC Mode)Sine waveOutput AC Waveform (Battery Mode)Pure Sine waveNominal Output Voltage(s) Supported220V; 230V; 240VOutput Receptacles(8) C13BATTERYBattery TypeValve Regulated Lead Acid (VRLA)Runtime Full Load (min.)8 min. (900W)Runtime Half Load (min.)20 min. (450W)DC System Voltage (VDC)36Battery Recharge Rate (Included Batteries)Less than 8 hours from 10% to 90% (typical, full load discharge)Battery AccessBattery access doorBattery Replacement DescriptionHot-swappable, user replaceable batteriesVOLTAGE REGULATIONVoltage Regulation DescriptionAutomatic voltage regulation (AVR) maintains line power operation with an input voltage range of 182 to 278 (230v), 190 to 290 (240v), 174 to 266 (220v)Overvoltage CorrectionVoltage reduction of 12% applies when input is 244 to 278 (230v), 254 to 290 (240v), 232 to 266 (220v); Voltage setpoints ±5% toleranceUndervoltage CorrectionVoltage boost of 14% applies when input is 182 to 206 (230v), 190 to 216 (240v), 174 to 198 (220); Voltage setpoints ±5% toleranceUSER INTERFACE, ALERTS & CONTROLSSwitches2 Switches control off/on power status and alarm-cancel/self-test operation; rear panel protected switches support nominal voltage selectionAlarm Cancel OperationPower-fail alarm can be silenced using alarm-cancel switchAudible AlarmAudible alarm indicates power failure and overload conditionsLED Indicators9 LEDs indicate line power, battery power, AVR, overload and replace battery status - with a 3-LED level meter for load and battery charge levelSURGE / NOISE SUPPRESSIONUPS AC Suppression Joule Rating350UPS AC Suppression Response TimeInstantaneousUPS Dataline Suppression1 line TEL/DSL (1 in / 1 out); 10/100Base T EthernetEMI / RFI AC Noise SuppressionYesPHYSICALPrimary Form FactorTowerCooling MethodFanInstallation Form Factors Supported with Included AccessoriesTowerPrimary UPS Depth (mm)335Primary UPS Height (mm)259Primary UPS Width (mm)173Shipping Dimensions (hwd / in.)18.50 x 10.00 x 13.50Shipping Weight (lbs.)47.30UPS Housing MaterialSteelUPS Power Module Dimensions (hwd, in.)10.2 x 6.8 x 13.2UPS Power Module Weight (kg)20.41UPS Power Module Weight (lbs.)45Unit Weight (lbs.)43.5000ENVIRONMENTALOperating Temperature Range32° to 104°F (0° to 40°C)Storage Temperature Range5° to 122°F (-15° to 50°C)Relative Humidity0 to 95%, non-condensingAC Mode BTU / Hr. (Full Load)145AC Mode Efficiency Rating (100% Load)94%Battery Mode Heat Dissipation (BTU/Hr) @ Full Load585Audible NoiseAudible Noise < 50 dBA at Front Side 1 MeterCOMMUNICATIONSNetwork Monitoring Port DescriptionSupports detailed monitoring of UPS and site power conditionsPowerAlert SoftwareFor local monitoring via the UPS’s built-in communication ports, download PowerAlert software at CableUSB and DB9 cabling includedWatchDog CompatibilitySupports Watchdog application, OS and hard-reboot restart options for remote applicationsNetwork Management Card DescriptionNetwork management card optionalCommunications InterfaceDB9 Serial; Slot for SNMP/Web interface; USBLINE / BATTERY TRANSFERTransfer Time4-8 millisecondsLow Voltage Transfer to Battery Power (Setpoint)174V (220V), 182V (230V) or 190V (240V); Voltage setpoints ±5% toleranceHigh Voltage Transfer to Battery Power (Setpoint)266V (220V), 278V (230V) or 290V (240V); Voltage setpoints ±5% toleranceFEATURES & SPECIFICATIONSCold Start (Startup in Battery Mode During a Power Failure)Cold-start operation supportedHigh Availability UPS FeaturesAuto Probe Monitoring (requires WEBCARDLXE); Automatic Voltage Regulation (AVR); Hot swappable batteries; Remote management; Surge/noise protectionAPPLICATIONSUPS ApplicationsLarge Network; High-End Desktop/Small NetworkSTANDARDS & COMPLIANCEProduct ComplianceRoHS; SASO (Saudi Arabia); CE (Europe); FCC Part 15 Class A (USA)
