✦ WiFi 6 · IP67 · 4×8dBi FIBERGLASS · PoE ✦WAVLINKOutdoor WiFi 6 Mesh AP Series · AX1800 WN573HX1 & AX3000 WN573HX3Rugged WiFi 6.
Two Tiers. One Outdoor Platform.
The (AX1800) and (AX3000) share the same industrial DNA — IP67 waterproof enclosure, 15kV ESD + lightning protection, 4 × 8dBi fiberglass tube antennas, and 802.3 AT/AF Active + Passive PoE. Choose your throughput tier and device capacity — from 128 devices on AX1800 up to 256 devices on AX3000. DevicesThe Complete LineupTwo Tiers. One Rugged Platform.
Both models deliver the same industrial-grade outdoor experience — the difference is throughput tier and device capacity. The AX1800 is the everyday workhorse; the AX3000 is the high-density flagship.
WiFi 6 · AX1800 · 128 Devices4 × 8dBi Fiberglass · 574Mbps + 1201Mbps · IP67 · 15kV ESDBEST FOREveryday outdoor WiFi 6 coverage — farms, yards, RV parks, and remote sitesWiFi 6 · AX3000 · 256 Devices4 × 8dBi Fiberglass · 573Mbps + 2402Mbps · IP67 · 15kV ESDBEST FORHigh-throughput 360° outdoor coverage — the mainstream flagship for dense deploymentsFeatureAX1800 WIfI 6AX3000 WiFi 6Wireless StandardIEEE 802.11 ax/ac/a/n/g/bIEEE 802.11 ax/ac/a/n/g/b2.4GHz Speed574 Mbps573 Mbps5GHz Speed1201 Mbps2402 MbpsTotal Speed1800 Mbps3000 MbpsAntennas4 × 8dBi Fiberglass Omni4 × 8dBi Fiberglass OmniMax DevicesUp to 128Up to 256Waterproof RatingIP67IP67Protection15kV ESD · Lightning Arrester15kV ESD · Lightning ArresterPoE Support802.3 AT/AF Active PoE + Passive PoEOperation ModesMesh / AP / Router / Repeater / AP+RepeaterAP / Range Extender / Mesh Router / Mesh ExtenderSecurityWPA2-PSK · WPA3/WPA2-MIXOPEN · WPA2-PSK · WPA3/WPA2 MIXEthernet Port1 × WAN/LAN GigabitProduct Size (no antennas)24 × 24 × 7cm / 9.4 × 9.4 × 2.8inUnit Weight (no antennas)1109g / 39.1ozMesh PairingWN531AX2 · WN583AX1 · WN573HX1WN586X3 · WN572HP3* · WN573HX301AX1800 WiFi6+4x 8dBi Antennas+up to 128 Devices
Up to 128 Devices · IP67 · 15kV ESD · PoE Ready
WiFi 6 · AX1800AX1800 WiFi 6 Outdoor Mesh Router/AP/Repeater with IP67 waterproof enclosure and 15kV ESD protection. Supports dual-band speeds up to 2.4G 573Mbps + 5G 1201Mbps with combined speeds up to 1800Mbps. Features 4 × 8dBi fiberglass tube antennas for high precision, corrosion resistance, long life, and strong wind resistance. Features Full capability list
- Robust weatherproof case, IP67 waterproof rating and built-in lightning arrester (15kV ESD) withstands harsh outdoor conditions.
- Supports 802.3 AT/AF active PoE and passive PoE to supply power.
- Fiberglass tube antennas for high precision, corrosion resistance, long life, strong wind resistance.
- 4 × 8dBi detachable omnidirectional external antennas provide excellent wireless performance.
- Supports dual band (2.4G 573Mbps + 5G 1201Mbps) with combined speeds of up to 1800Mbps.
- Mesh technology makes you enjoy seamless roaming throughout the house with a single network name and password.
- Complies with IEEE 802.11 ax/ac/a/n/g/b standards.
- Supports Mesh / AP / Router / Repeater / AP+Repeater modes.
- Encryption type: WPA2-PSK, WPA3/WPA2-MIX.
- One WAN/LAN Gigabit port delivers wired-grade stability for your outdoor wireless network.
📡4 × 8dBi Fiberglass Tube Antennas
4 × 8dBi detachable omnidirectional external antennas provide excellent wireless performance. The fiberglass tube design resists corrosion, wind, and UV exposure — ideal for coastal, farm, and rooftop deployments where durability matters most. Each antenna is 40cm / 15.7in long and uses standard connectors.
Specification Tech dataModelAX1800 WiFi6+4x 8dBi Antennas+up to 128 Devices Product Size (without antennas)24 × 24 × 7cm / 9.4 × 9.4 × 2.8inPoE Converter Size4.4 × 3.7 × 2.2cm / 1.7 × 1.5 × 0.9inCable LengthAntennas — 40cm / 15.7in
Ethernet — 100cm / 39.4in
Power Adapter — 130cm / 51.2inProduct Weight (without antennas)1109g / 39.1ozStandardIEEE 802.11 ax/ac/a/n/g/bFrequency Band / Speed2.4GHz (574Mbps) + 5GHz (1201Mbps)Wireless SecurityWPA2-PSK, WPA2/WPA3-MIXAntennas4 × 8dBi Omnidirectional Antennas (Fiberglass Tube)PAIR/RESET LEDBluePoE Converter Status LEDGreenWaterproof RatingIP67 — weatherproof outdoor enclosureProtection15kV ESD · Lightning ArresterCompatible Systems Network environmentMesh · AP · Router · Repeater · AP+RepeaterWPA2-PSKWPA3/WPA2-MIX✘ Captive Portal RepeaterHow to Install Antennas & Ethernet Cable Waterproof setup1Pass the Cable
Pass the RJ45 cable through the waterproof connector cover.
2Seal Bracket
Screw the waterproof seal into the waterproof connector bracket.
3Bracket to Cover
Pass cable through the bracket and screw the bracket into the cover.
4Sealing Ring
Put the waterproof sealing ring on the waterproof connector bracket.
5Connect Port
Connect the RJ45 cable to the WAN/LAN port.
6Screw Antennas
Screw the connecting cable into the 2.4G and 5G antenna connector and tighten.
How to Install on a Column Pole mounting1Silicone Pads
Stick two silicone pads on the bracket and post respectively.
2Thread Cable Ties
Thread the cable ties through the fixing point of the bracket.
3Fix to Post
Fix the product to the post with cable ties.
Warm Tips Read before installPlease read before installation
- ①The PoE converter is not waterproof, please install it indoors.
- ②Please make sure your Ethernet cable is CAT5E or above certified and shorter than 100m / 328ft.
- ③Please install the product 2–3 meters above the ground for better performance.
- ④Under Mesh mode, WN573HX1 ONLY supports interconnection with WN531AX2, WN583AX1 and WN573HX1.
In the Box What you get📶Wi-Fi 6 Outdoor Mesh Router/AP/RepeaterWN573HX1 main unit📡4 × Omni Antennas8dBi · 40cm each🔗Ethernet Cable ConnectorsWaterproof connectors🎗️4 × Cable TiesClean cable management🔧WrenchFor antenna installation🧲2 × Silicone PadsSealing and vibration damping🔩Several ScrewsMounting hardware kit📖Quick Installation GuideSetup instructionsPassive PoE (Optional): 1 × 54V Power Adapter · 1 × PoE Converter · 1 × Ethernet Cable 02AX3000 WiFi6+4x 8dBi Antennas+up to 256 Devices
3000Mbps · IP67 · 15kV ESD · PoE Ready
WiFi 6 · AX3000AX3000 WiFi 6 Outdoor Access Point with IP67 waterproof enclosure and 15kV ESD protection. Supports dual-band speeds up to 2.4G 573Mbps + 5G 2402Mbps with aggregated speeds up to 3000Mbps. Features 4 × 8dBi fiberglass tube antennas for high precision, corrosion resistance, long life, and strong wind resistance. Features Full capability list
- Supports for dual band (2.4G 573Mbps + 5G 2402Mbps) with aggregated speeds up to 3000Mbps.
- Supports one WAN/LAN Ethernet Gigabit port.
- Complies with IEEE 802.11 ax/ac/a/n/g/b standards.
- Supports AP / Range Extender / Mesh Router / Mesh Extender mode.
- Encryption type: OPEN, WPA2-PSK, WPA3/WPA2 MIX.
- 2 × 8dBi 5GHz and 2 × 8dBi 2.4GHz detachable omni-directional external antennas provide excellent wireless performance.
- Glass tube antenna for high precision, corrosion resistance, long life, strong wind resistance.
- Seamless and stable WiFi Mesh makes you enjoy seamless roaming throughout the house with a single network name and password.
- Robust weatherproof case and IP67 waterproof grade withstand harsh outdoor conditions.
- Supports 802.3 AT/AF Active PoE and Passive PoE to supply power.
📡4 × 8dBi Fiberglass Tube Antennas — Band-Dedicated
2 × 8dBi 5GHz and 2 × 8dBi 2.4GHz detachable omni-directional external antennas provide excellent wireless performance. The fiberglass tube design resists corrosion, wind, and UV exposure — with dedicated antennas per band, each frequency gets full beam-forming strength without compromise.
Specification Tech dataModelAX3000 WiFi6+4x 8dBi Antennas+up to 256 Devices Product Size (without antennas)24 × 24 × 7cm / 9.4 × 9.4 × 2.8inPoE Converter Size4.4 × 3.7 × 2.2cm / 1.7 × 1.5 × 0.9inCable LengthAntennas — 40cm / 15.7in
Ethernet — 100cm / 39.4in
Power Adapter — 130cm / 51.2inProduct Weight (without antennas)1109g / 39.1ozStandardIEEE 802.11 ax/ac/a/n/g/bFrequency Band / Speed2.4GHz (573Mbps) + 5GHz (2402Mbps)Wireless SecurityWPA2-PSK, WPA2/WPA3-MIXAntennas4 × 8dBi Omnidirectional Antennas (2 × 5GHz + 2 × 2.4GHz Fiberglass Tube)PAIR/RESET LEDBluePoE Converter Status LEDGreenWaterproof RatingIP67 — weatherproof outdoor enclosureProtection15kV ESD · Lightning ArresterCompatible Systems Network environmentAP · Range Extender · Mesh Router · Mesh ExtenderOPENWPA2-PSKWPA3/WPA2 MIXHow to Install Antennas & Ethernet Cable Waterproof setup1Pass the Cable
Pass the RJ45 cable through the waterproof connector cover.
2Seal Bracket
Screw the waterproof seal into the waterproof connector bracket.
3Bracket to Cover
Pass cable through the bracket and screw the bracket into the cover.
4Sealing Ring
Put the waterproof sealing ring on the waterproof connector bracket.
5Connect Port
Connect the RJ45 cable to the WAN/LAN port.
6Screw Antennas
Screw the connecting cable into the 2.4G and 5G antenna connector and tighten.
How to Install on a Column Pole mounting1Silicone Pads
Stick two silicone pads on the bracket and post respectively.
2Thread Cable Ties
Thread the cable ties through the fixing point of the bracket.
3Fix to Post
Fix the product to the post with cable ties.
Warm Tips Read before installPlease read before installation
- ①The PoE converter is not waterproof, please install it indoors.
- ②Please make sure your Ethernet cable is CAT5E or above certified and shorter than 100m / 328ft.
- ③Please install the product 2–3 meters above the ground for better performance.
- ④Under Mesh mode, WN573HX3 supports interconnection with WN586X3, WN572HP3 (*Latest firmware required) and WN573HX3.
In the Box What you get📶AX3000 WiFi 6 Outdoor Access PointWN573HX3 main unit📡4 × 8dBi Omni Antennas2 × 5GHz + 2 × 2.4GHz · 40cm each🔗Ethernet Cable ConnectorsWaterproof connectors🎗️4 × Cable TiesClean cable management🔧WrenchFor antenna installation🧲2 × Silicone PadsSealing and vibration damping🔩Several ScrewsMounting hardware kit📖Quick Installation GuideSetup instructionsPassive PoE (Optional): 1 × 54V Power Adapter · 1 × PoE Converter · 1 × Ethernet Cable WAVLINKOutdoor WiFi 6 · AX1800 / AX3000 · IP67 · 4×8dBi · PoE · MeshRugged WiFi 6. Two Tiers. One Platform.
From AX1800 to AX3000 — industrial-grade outdoor wireless with fiberglass antennas, IP67 protection, and PoE flexibility.
AX1800 · WN573HX11800Mbps · up to 128 devices · 4 × 8dBi fiberglass antennas · IP67.AX3000 · WN573HX33000Mbps · up to 256 devices · 4 × 8dBi fiberglass antennas · IP67.IP67 + 15kV ESDWeatherproof housing with lightning arrester — built for rain, snow, wind, and thunder.PoE Active + Passive802.3 AT/AF plus Passive PoE — single-cable install up to 100m. Both models share the same physical design and mounting hardware. Choose AX1800 for everyday outdoor WiFi 6, or AX3000 for high-density flagship performance.
The PoE converter is not waterproof — install it indoors. Use CAT5E or above cable, max 100m / 328ft.
Install the product 2-3 meters above the ground for better performance. Actual performance varies with environmental conditions.
Mesh compatibility varies by model — WN573HX1 pairs with WN531AX2 / WN583AX1; WN573HX3 pairs with WN586X3 / WN572HP3 (latest firmware) / WN573HX3.
