Waveshare 4inch DSI Round Capacitive Touch Display, 720×720 IPS Display 10-Point For Sale

When you click on links to various merchants on this site and make a purchase, this can result in this site earning a commission. Affiliate programs and affiliations include, but are not limited to, the eBay Partner Network.

Waveshare 4inch DSI Round Capacitive Touch Display, 720×720 IPS Display 10-Point

Price: CN $84.62

Description
3.4 / 4inch DSI Round Capacitive Touch Display, 800 × 800 / 720 × 720 Resolution, IPS display panel, 10-Point Touch3.4 / 4inch DSI Round Touch Display

High Resolution | Multi-touch | Full Color

Display InterfaceDSI
Display PanelIPS
Viewing Angle170°
Touch TypeCapacitive
Touch Points10-Point
Touch InterfaceI2C
Touch PanelToughened Glass
Touch Panel TechOptical Bonding

Version Options

3.4-DSI-TOUCH-C
3.4inch round touch display, 800 × 800 resolution

4-DSI-TOUCH-C
4inch round touch display, 720 × 720 resolution

Device & System Support
Raspberry PiSupports Raspberry Pi OS, 10-point touch
RK3506Supports Buildroot, Ubuntu, and other systems, 10-point touch
ESP32-P4Supports LVGL GUI programs, 10-point touch
RK3576Supports Buildroot, Debian, Ubuntu, Android, and other systems, 10-point touch
LCD × 800 pixels (H×V)720 × 720 pixels (H×V)Display Color Gamut70% NTSC60% NTSCContrast Ratio1200:1Display ICJD9365Touch ICGT928Communication Interface2-lane MIPI DSIBrightness300cd/m²550cd/m²Outline Dimensions115.00 × 115.00 (mm)126.00 × 126.00 (mm)Display Area87.60 × 87.60 (mm)101.52 × 101.52 (mm)Operating Temperature0℃ ~ 60℃Connection Examples

Working with Raspberry Pi 5

Working with Raspberry Pi 4B

Working with ESP32-P4-Module-DEV-KIT

Working with Luckfox Omni3576

Working with Luckfox Lyra

* for reference only, the above boards or hosts are NOT included.

IPS Display Panel

Excellent Display Performance With 170° Wide Viewing Angle

10-Point Capacitive Touch
