X99 PR9 Motherboard Intel LGA 2011-3 DDR4 Max 128GB M-ATX

Product description SHANGZHAOYUAN X99 PR9 Computer Motherboard, crafted to support diverse environments such as design, games, and efficient office.

Frequently Asked Questions

• Computer won't start, fan doesn't spin, indicator lights are off

Check CPU compatibility or damage; check motherboard and CPU power supplies; check power button cable; check power switch on; check power supply; disconnect graphics card, hard drive, USB devices, etc., then try powering on again; clear CMOS.

• The fan spins briefly and then immediately shuts off, or the computer repeatedly restarts

Clear the CMOS; check CPU and memory compatibility or damage; disconnect the graphics card, hard drive, USB devices, etc., and then try powering on.

• The fan is spinning, but pressing the Caps Lock key on the keyboard doesn't activate the indicator lights

Try clearing the CMOS; checking that the motherboard and CPU power supplies are properly connected; checking for CPU and memory compatibility issues or damage; and checking that the memory is installed correctly.

• The fan is spinning. Pressing the Caps Lock key on the keyboard illuminates the indicator light, but there is no display

Check if the monitor is powered on or damaged; check if the display data cable is properly connected or damaged; check if the graphics card is working properly.

• Blue screen, system crash

Check if the CPU cooling fan is spinning and if the cooling fan base is properly seated on the CPU; replace the CPU, memory, hard drive, operating system, and power supply.

Note:

1. The user manual is not included in the package, if you need it, please download the user manual file from the bottom of the product description page or let us help you get it.
2. The motherboard does not include a CR2032 battery, please purchase one yourself.
3. The boot is slow, about 40s, we don't recommend buying it if you mind, so as not to bring you trouble, please forgive me.

Intel LGA 2011-3 Socket

Support Xeon E5 V3 V4 LGA 2011-3 CPU (e.g. E5 2640 V3/E5 2650 V3/E5 2666 V3/E5 2673 V3/E5 2682 V4/E5 2690 V4/E5 2667 V4/E5 2640 V4/E5 2630 V4, etc.)

Dual-channel DDR4

Support DDR4 ECC/NON-ECC memory up to 128GB (4*32GB). And support 2133MHz/2400MHz frequency.

If installing 1 RAM, please install it in slot 4.

If installing 2 RAMs, please install them in slots 1 and 4.

PCle Interface

Using PCIe 3.0 technology compared with 2.0 speed increased by two times, play the game without delay, and screen rendering ability.

Stable Power Supply

Using 6-phase power supply, and all-solid-state capacitors, voltage and current stability, the equipment has long life and durability.

SATA 3.0

Output read and write speed is extremely fast, offer farewell to the phenomenon of stuttering, and refuse to delay.

10-layer PCB Material

With the use of 10-layer PCB board synthesis, the motherboard is durable and will not break easily.

X99 PR9 LGA 2011-3 Motherboard Specifications Main Chipset Q85 Chipset CPU Socket LGA 2011-3 Memory Slot 4*DDR4 Maximum Memory 128GB (32GB*4) PCIe Slot PCIe 3.0 x16; PCIe x1 Display port No (Requires graphics card) Onboard Network Card Gigabit LAN Interface Storage Interface 3*SATA 3.0; NVME/NGFF M.2 USB Interface 3*USB 3.0; 7*USB 2.0 Power Supply 6-phase Power Supply Power Connector 24PIN+8PIN FAN Interface 1*4PIN; 1*3PIN Motherboard Size 215mm*185mm Packing List 1*motherboard, 1*I/O blocking, 2*SATA cable, 1*CPU cooler bracket Add to Cart Add to Cart Add to Cart Add to Cart Add to Cart Customer Reviews 3.6 out of 5 stars 10 3.4 out of 5 stars 13 3.9 out of 5 stars 23 3.9 out of 5 stars 17 4.2 out of 5 stars 11 Price $61.99$61.99 $65.99$65.99 $55.99$55.99 $184.99$184.99 $133.99$133.99 Main Chipset Intel 8 Series Chipsets Intel C612 Chipset Intel H55 Chipsets Intel C612 Chipset Intel C612 Chipset CPU Socket LGA 2011-3 LGA 2011-3 LGA 2011-3 LGA 2011-3 LGA 2011-3 Memory Slot 4*DDR4(up to 128GB) 4*DDR4(up to 128GB) 4*DDR4(up to 128GB) 8*DDR4 (up to 256GB) 8*DDR4 (up to 256GB) Network Card 1*Gigabit LAN Interface 1*Gigabit LAN Interface 1*Gigabit LAN Interface 2*Gigabit LAN Interface 2*Gigabit LAN Interface Display Port No(Requires graphics card) No(Requires graphics card) No(Requires graphics card) No(Requires graphics card) No(Requires graphics card) Motherboard Size 215*185mm 245*190mm 215*185mm 305mm*330mm 300*330mm

• LGA 2011-v3 Motherboard: The Intel motherboard is designed with LGA2011-3 socket, support Xeon E5 V3 V4 and Core i7 series processors. (e.g. E5 2680 V3/E5 2676 V3/E5 2666 V3/E5 2650 V3/E5 2680 V4/E5 2683 V4/E5 2650 V4/E5 2697 V4, i7 6800K etc.)
• Dual-channel DDR4: The Intel LGA2011-v3 motherboard supports DDR4 memory up to 128GB (4*32GB), and supports 2133MHz/2400MHz (Overclocking is not supported), when using E5 V4 and i7 series CPUs, only ECC memory is supported
• Stable Power Supply: 6-phase power supply, all-solid-state capacitor design, fine workmanship, professional stability. And the DDR4 motherboard is equipped with 24+8 pin power interface (please use a brand power supply of at least 500w)
• Rich Interfaces: The computer motherboard features RJ45 gigabit network interfaces, and the maximum network transmission rate can reach 1000bps/s. And with M. 2 slot (support NVME SSD/NGFF SSD), PCIe 3.0 X16, PCIe x1, SATA 3.0, USB 3.0, USB 2.0
• High Performance Mainboard: The X99 motherboard is equipped with Q85 chipset, 10-layer PCB material. And the placa madre with Heat dissipation armor protection for strong heat dissipation, to ensure stable bus communication
• Package lists: 1* X99 PR9 motherboard, 1*SATA cable, 1*I/0 shield, 1*LGA2011-3 cooler bracket. IMPORTANT: The package does not contain a user manual. If you need the manual file, please download it from the product description page " Product guides and documents" or ask us on Amazon to get it. And the motherboard does not include a CR2032 battery, please purchase one yourself
• Warm Tips: The boot is slow, about 40s. If no display, no boot, no screen, no network card, no sound card, etc., please ask us for help on Amazon. It is recommended driver download: Driver Talent. or use Win 10 system, it can help you solve all the driver problems

• Processor Socket LGA 2011-3 Compatible Devices Personal Computer, Server RAM Memory Technology DDR4 Compatible Processors Intel LGA 2011-3 Socket CPUs Chipset Type Intel Q85 Chipset Memory Clock Speed 2133 MHz Platform Windows 10 CPU Model Intel Xeon Memory Storage Capacity 128 GB Ram Memory Maximum Size 128 GB Main Power Connector Type 24 + 8 pin Graphics Card Interface PCI Express Number of Ports 16 S/PDIF Connector Type Optical System Bus Standard Supported SATA 3 Total SATA Ports 3 USB 20 6 Total Usb Ports 8 Number of Ethernet Ports 1 Total PCIe Ports 2 Chipset Family Q85 Model Name X99 PR9 Model Number X99 PR9 Item Highlight Support Intel Xeon E5 V3 V4 and Core i7 5th/6th Series Processors, PCIe 3.0, M.2 Protocol, SATA 3.0, USB 3.0, Gigabit LAN Number of Items 1 CPU Socket LGA 2011-3
