Transition Networks M/GEPSWPSE01NA PoE Media Converter Transition Networks M/GEPSWPSE01NA PoE Media Converter

International Customers: All electronic products are packaged for sale in the US with US voltage.

NDAA Compliant: Yes

Package Contents: M/GE-PSW-PSE-01 Transceiver/Media Converter Power Supply - North America

Certifications & Standards: EN55032-2012 Class A, IEC 61850-3:2002, EN55024-2010, CE Mark, Power Supply is UL listed

TAA Compliant: Yes

Additional Information: 10/100/1000Base-T PoE+ RJ-45 port [100 m/ 328 ft.] to 100/1000Base-X SFP slot (empty)

Application/Usage:

VoIP Phone
Security Camera
Wireless Access Compliance:

Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Restriction of Hazardous Substances (RoHS)
Waste Electrical and Electronic Equipment Directive (WEEE)

Product Description

This item is brand-new, factory sealed.

Mini Fast / Gigabit Ethernet PoE+ Media Converter

10/100/1000Base-T PoE+ RJ-45 Port + 100/1000Base-X SFP Slot

This Gigabit Ethernet Stand-alone Mini Media Converter provides cost-effective media conversion between 10/100/1000Base-T ports and 100/1000Base-SX/LX ports. With its fixed configuration, deployments are just plug-and-play, and its small size makes it ideal for locations where space is limited. Operating at Layer 2, the data link layer, this converter not only converts copper to fiber, but it also provides rate conversion allowing legacy 10/100 copper devices to connect to 1000Base-SX/LX fiber.

In addition to providing copper to fiber conversion, this converter is also classified as Power Sourcing Equipment (PSE), meaning it combines data received over the fiber optic link with 56VDC input power to provide power and data to a Powered Device (PD) over the twisted Pair cable, while complying with the IEEE 802.3af and IEEE 802.3at PoE+ standards. This allows the user to take advantage of the benefits of fiber cabling, along with the benefits of Power-over-Ethernet (PoE) technology.

Supporting PoE allows this converter to send data and power to devices like VoIP Phones, Security Cameras, and Wireless Access Points, especially if they need to be located in remote areas of your network that can only be reached with fiber optic cabling.

Package Contents:

M/GE-PSW-PSE-01 Transceiver/Media Converter

Power Supply - North America

SpecificationPower DescriptionPower SourceAC/DCInput Voltage56 V DCPower Consumption34 WPhysical CharacteristicsForm Factor

• Wall Rail (Approximate)2 WarrantyLifetimeInterfaces/PortsNetwork (RJ-45)YesTotal Number of Ports1PoE Port TypePSENumber of PoE+ (RJ-45) Ports1I/O ExpansionsTotal Number of Expansion Slots1Number of SFP Slots1Expansion Slot TypeSFPGeneral InformationBrand NameLantronixMarketing Information This Gigabit Ethernet Stand-alone Mini Media Converter provides cost-effective media conversion between 10/100/1000Base-T ports and 100/1000Base-SX/LX ports. With its fixed configuration, deployments are just plug-and-play, and its small size makes it ideal for locations where space is limited. Operating at Layer 2, the data link layer, this converter not only converts copper to fiber, but it also provides rate conversion allowing legacy 10/100 copper devices to connect to 1000Base-SX/LX fiber. In addition to providing copper to fiber conversion, this converter is also classified as Power Sourcing Equipment PSE, meaning it combines data received over the fiber optic link with 56VDC input power to provide power and data to a Powered Device PD over the twisted Pair cable, while complying with the IEEE 802.3af and IEEE 802.3at PoE+ standards. This allows the user to take advantage of the benefits of fiber cabling, along with the benefits of Power-over-Ethernet PoE technology. Supporting PoE allows this converter to send data and power to devices like VoIP Phones, Security Cameras, and Wireless Access Points, especially if they need to be located in remote areas of your network that can only be reached with fiber optic cabling. NDAA Compliant, TAA Compliant Product TypeTransceiver/Media ConverterProduct NameM/GE-PSW-PSE-01 Transceiver/Media ConverterManufacturerLantronix, IncManufacturer Part NumberM/GE-PSW-PSE-01-NAProduct ModelM/GE-PSW-PSE-01Media & PerformanceMaximum Distance Supported0.10 kmMedia Type Supported
  • Optical Fiber
  • Twisted Pair
  TitleProduct TitleMini Fast / Gigabit Ethernet PoE+ Media Converter 10/100/1000Base-T PoE+ RJ-45 Port + 100/1000Base-X SFP Slot (M/GEPSWPSE01NA)Network & CommunicationEthernet TechnologyGigabit EthernetNetwork Technology
