AC Input Voltage85 VAC to 300 VAC, 187 VAC to 264 VAC (nominal)
Frequency45 Hz to 65 Hz
Maximum Current12 A
Power Factor>0.99 from 50 to 100% load
DC Output Voltage-42 VDC to -58 VDC
Maximum Power2000 W
Maximum Current42 A @ -48 VDC, limit set point 0 to 42 A (see figure 2)
Peak Efficiency96.2%
Temperature DeratingFull output power up to +65°C at input voltage range 200 to 250 VAC
SignalingAlarm and status reported via CAN bus to system controller
StandardsEN 60950-1; IEC 60950-1; UL 60950-1 EMC EN55022, CISPR22, ETSI EN300 286
