SHIPS SAME DAY
The 2000 watt high-efficiency eSure rectifier (model R48-2000e3) converts standard AC supply voltages into stable nominal -48 VDC voltage that is adjustable to application needs. This constant power rectifier designed with the latest patented switch-mode technology, uses DSP (Digital Signal Processing) for efficient operation. The R48-2000e3 can be connected in parallel with other rectifiers and converters to support a variety of telecom applications. Unified remote management and control of the power system is enabled when combined with a Vertiv controller.
Technical Specifications AC Input Voltage 85 VAC to 300 VAC, 187 VAC to 264 VAC (nominal)
Frequency 45 Hz to 65 Hz
Maximum Current 12 A
Power Factor >0.99 from 50 to 100% load
DC Output Voltage -42 VDC to -58 VDC
Maximum Power 2000 W
Maximum Current 42 A @ -48 VDC, limit set point 0 to 42 A (see figure 2)
Peak Efficiency 96.2%
Temperature Derating Full output power up to +65°C at input voltage range 200 to 250 VAC
Signaling Alarm and status reported via CAN bus to system controller
Standards EN 60950-1; IEC 60950-1; UL 60950-1 EMC EN55022, CISPR22, ETSI EN300 286
Dimensions (H x W x D) 41 x 84.5 x 252.5 mm / 1.61 x 3.33 x 9.94 inches
Weight 1.13 kg / 2.49 lbsThis listing is for the actual item in the photograph in the condition pictured, we do not use only stock images. Please take a moment to review all pictures of the item. The package you receive will contain only what is in the pictures nothing more and nothing less.
Please Inquire if Necessary
